The IVGM6KLP1G1 is a 6 kW single-phase hybrid inverter whose two MPPT trackers are laid out 2+1 strings for 26+13 A, with 135 A of battery charging and discharging and 28.7 A of maximum output current at 220-230 V.
In stock
The Felicity Solar IVGM6KLP1G1 is a single-phase hybrid solar inverter rated 6 kW and 6 kVA, with 6.6 kW of maximum AC output power, up to 9 kW of recommended PV power on two MPPT trackers, a 40-60 V battery window charged and discharged at 135 A, and 97.6% maximum efficiency. The trackers are asymmetric, two strings on one and one on the other, taking 26+13 A of input current and 44+17 A of short-circuit current to a 500 V ceiling, tracking 120-425 V from a 100 V start-up and holding full load 230-425 V around a 380 V rated PV input voltage at 99.9% tracking efficiency. AC output is 220-230 V on L+N+PE wiring, 26.1 A rated and 28.7 A maximum, with 40 A of backup current behind the 6 kW backup output, a 10 ms transfer time, twice rated power for 10 seconds and THD below 3%. The isolated, transformer-based body is smart-cooled, IP65, 430 x 654 x 243 mm and 33.5 kg net, and parallels to 6 units. We are an authorised Felicity Solar distributor and supply the IVGM6KLP1G1 from our own stock, with a 2 Years warranty.
Specifications last updated 17 August 2026
| AC Output Voltage | 220-230 V |
|---|---|
| AC Rated Output Current | 26.1 A |
| AC Wiring Mode | L+N+PE |
| Backup Max Output Current | 40 A |
| Backup Rated Output Power | 6 kW |
| Battery Inputs | 1 |
| Battery Type | Lead-Acid, Li-Ion |
| Battery Voltage Range | 40-60 V |
| Charge Algorithm | Self-Adaption to BMS |
| Grid Frequency Range (50 Hz) | 45-55 Hz |
| Grid Frequency Range (60 Hz) | 55-65 Hz |
| Grid Regulation | VDE 4105, CEI 0-21, G99, NRS 097-2-1, EN 50549-1, EN 50549-10, NC RFG (Poland), EN 50549-1/-10+Netherlands, PPDS, NTS & UNE217001 & UNE217002, UL1741 (in progress) |
| Ground Fault Current Monitoring | Yes |
| MPPT Efficiency | 99.9 % |
| MPPT Full-Load Voltage Range | 230-425 V |
| MPPT Trackers | 2 |
| MPPT Voltage Range | 120-425 V |
| Max AC Input Current | 40 A |
| Max AC Output Power | 6.6 kW |
| Max AC Pass-Through Current | 40 A |
| Max Charge/Discharge Power | 6 kW |
| Max Charging Current | 135 A |
| Max Discharging Current | 135 A |
| Max Efficiency | 97.6 % |
| Max Output Current | 28.7 A |
| Max PV Input Current | 26+13 A |
| Max PV Voltage | 500 V |
| Max Recommended PV Power | 9 kW |
| Max Short-Circuit Current | 44+17 A |
| Nominal AC Input Voltage | 220-230 V |
| Nominal Input Frequency | 50/60 Hz |
| Output Frequency | 50/60 Hz |
| Output Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| PV Working Voltage Range | 90-500 V |
| Phase | Single Phase |
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging |
| Protection | Output Over Current Protection, Output Over Power Protection, Output Short-Circuit Protection, Anti-islanding Protection, GFCI Protection, Arc Fault Circuit Interrupter (AFCI), Insulation Resistor Detection |
| Rated Apparent Output Power | 6 kVA |
| Rated Output Power | 6 kW |
| Rated PV Input Voltage | 380 V |
| Start-Up Voltage | 100 V |
| Strings per MPPT | 2+1 |
| Surge Rating | 2*rated (10s) |
| Total Harmonic Distortion | <3 % |
| Transfer Time | 10 ms |
| BMS Communication | RS485, CAN |
|---|---|
| Communication Interface | RS232, RS485 |
| Display | LCD, LED |
| Gross Weight | 40.5 kg |
| Installation Style | Wall-Mounted |
| Monitoring Module | WiFi/GPRS |
| Net Weight | 33.5 kg |
| Package Dimensions | 787 x 547 x 358 mm |
| Parallel Capability | 6 |
| Safety Standard | IEC 62109-1, IEC 62109-2 |
| Topology | Isolated (transformer-based) |
| Cooling | Smart Cooling |
|---|---|
| IP Rating | IP65 |
| Operating Temperature Range | -25 to 60 (>45 derating) °C |
Twenty-five Felicity inverters are IP21 and every SCCM charge controller says indoor wall-mount. IP20, IP21 and IP31 are indoor ratings, and the first digit - the dust one - is the half nobody reads. Here is which listing carries which.
Read: Can I Install a Solar Inverter Outside? What IP21, IP31 and IP65 Really Mean →An off-grid house is sized by surge, battery energy and charge current - and the surge row is the one that starts your fridge and your pump. Here are the published figures across the Felicity inverters and batteries, with the arithmetic to use them.
Read: How to Run a Whole House on Solar in Khartoum →Sana'a sits above 2,000 metres, and an inverter whose datasheet permits 2,000 m is not rated for the city at all. Here is the altitude row on 44 Felicity listings, model by model, and which ones cover your elevation.
Read: Which Solar Inverters Actually Work in Sana'a? →9 kW is the maximum recommended PV power, over two MPPT trackers laid out 2+1 strings. They take 26+13 A of input current and 44+17 A of short-circuit current, track from 120 to 425 V after a 100 V start-up, hold full load from 230 to 425 V around a 380 V rated PV input voltage, and accept up to 500 V, with the PV working range spanning 90-500 V at 99.9% MPPT efficiency.
135 A is both the maximum charging current and the maximum discharging current, into a single battery input covering 40-60 V, for a maximum charge and discharge power of 6 kW. Lead-Acid and Li-Ion packs are supported, and the charge algorithm self-adapts to the BMS over RS485 and CAN.
6 kW rated output power and 6 kVA rated apparent output power, single phase at 220-230 V on L+N+PE wiring, with 6.6 kW of maximum AC output power. Rated output current is 26.1 A, maximum output current 28.7 A and backup output current 40 A behind the 6 kW backup output, with a 10 ms transfer time, twice rated power for 10 seconds, THD below 3% and 97.6% maximum efficiency. AC input draws up to 40 A and passes 40 A through, at 50/60 Hz across 45-55 Hz and 55-65 Hz windows.
430 x 654 x 243 mm and 33.5 kg net, 40.5 kg gross in a 787 x 547 x 358 mm carton. The wall-mounted, smart-cooled chassis is rated IP65 and runs from -25 to 60 °C with derating above 45 °C, monitored over WiFi or GPRS with RS232 and RS485 interfaces and an LCD and LED panel. Up to 6 units run in parallel, and the warranty is 2 Years.
