Felicity Solar IVGM8KLP1G1 8000W Hybrid Inverter

Felicity Solar IVGM8KLP1G1 8kW Single-Phase Hybrid Solar Inverter

An 8 kW hybrid inverter that reaches 8.8 kW of AC output and 38.3 A, tracks two solar strings across 120-425 V, and carries a 40-60 V battery bank on a single input.

Rated Output Power: 8 kW
Max Efficiency: 97.6 %
Battery Voltage Range: 40-60 V
Phase: Single Phase

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar IVGM8KLP1G1 8kW Single-Phase Hybrid Solar Inverter features

8 kW rated output, 8.8 kW maximum AC output

The IVGM8KLP1G1 is rated 8 kW (8 kVA apparent) and peaks at 8.8 kW of AC output and 38.3 A, above its 34.8 A rated output current, with a surge of 2x rated power for 10 s.

12 kW of recommended PV across two MPPT trackers

Two trackers run from 120 to 425 V, hold full load from 230 to 425 V and work across a 90-500 V window, taking two strings each at 26+26 A up to a 500 V maximum PV voltage.

97.6% maximum efficiency and 99.9% MPPT efficiency

Conversion peaks at 97.6% while tracking holds 99.9%, and the 220-230 V, 50/60 Hz single-phase output stays under 3% total harmonic distortion with a 0.8 leading to 0.8 lagging power factor range.

40-60 V battery bank charged and discharged at 190 A

One battery input takes Lead-Acid or Li-Ion packs at up to 190 A and 8 kW in either direction, with a charge algorithm that self-adapts to the BMS over RS485 or CAN.

10 ms transfer with 8 kW of backup power

Backup rated output power is 8 kW with a 40 A backup maximum output current, wired L+N+PE and backed by anti-islanding, GFCI, AFCI and insulation resistor detection.

IP65 wall-mounted unit at 430 x 654 x 243 mm and 33.5 kg net

Smart cooling holds -25 to 60 °C operation with derating above 45 °C, gross weight is 40.5 kg, monitoring runs over WiFi/GPRS on an LCD and LED display, and up to 6 units work in parallel.

About the Felicity Solar IVGM8KLP1G1 8kW Single-Phase Hybrid Solar Inverter

The Felicity Solar IVGM8KLP1G1 is an 8 kW single-phase hybrid inverter rated 8 kVA apparent, peaking at 8.8 kW of AC output and 38.3 A, working from a 40-60 V battery bank on one battery input and reaching 97.6% maximum efficiency. Two MPPT trackers cover 120-425 V and accept up to 12 kW of recommended PV power. On the array side each tracker takes two strings, 26+26 A and 500 V maximum, starting at 100 V and tracking at 99.9% efficiency. Charge and discharge both run to 190 A and 8 kW with Lead-Acid or Li-Ion packs, the charge algorithm self-adapting to the BMS over RS485 or CAN. Output is 220-230 V at 50/60 Hz on L+N+PE wiring, 34.8 A rated, under 3% THD, with 8 kW of backup rated power, 40 A backup maximum output current and a 10 ms transfer time. Protection covers output over-current, over-power and short circuit, anti-islanding, GFCI, arc fault (AFCI) and insulation resistor detection, to IEC 62109-1 and IEC 62109-2. The IP65 wall-mounted unit measures 430 x 654 x 243 mm and weighs 33.5 kg net; up to 6 run in parallel. We are an authorised Felicity Solar distributor. Warranty: 2 Years.

Specifications last updated 17 August 2026

Felicity Solar IVGM8KLP1G1 8kW Single-Phase Hybrid Solar Inverter full specifications

Electrical

AC Output Voltage	220-230 V
AC Rated Output Current	34.8 A
AC Wiring Mode	L+N+PE
Backup Max Output Current	40 A
Backup Rated Output Power	8 kW
Battery Inputs	1
Battery Type	Lead-Acid, Li-Ion
Battery Voltage Range	40-60 V
Charge Algorithm	Self-Adaption to BMS
Grid Frequency Range (50 Hz)	45-55 Hz
Grid Frequency Range (60 Hz)	55-65 Hz
Grid Regulation	VDE 4105, CEI 0-21, G99, NRS 097-2-1, EN 50549-1, EN 50549-10, NC RFG (Poland), EN 50549-1/-10+Netherlands, PPDS, NTS & UNE217001 & UNE217002, UL1741 (in progress)
Ground Fault Current Monitoring	Yes
MPPT Efficiency	99.9 %
MPPT Full-Load Voltage Range	230-425 V
MPPT Trackers	2
MPPT Voltage Range	120-425 V
Max AC Output Power	8.8 kW
Max AC Pass-Through Current	50 A
Max Charge/Discharge Power	8 kW
Max Charging Current	190 A
Max Discharging Current	190 A
Max Efficiency	97.6 %
Max Output Current	38.3 A
Max PV Input Current	26+26 A
Max PV Voltage	500 V
Max Recommended PV Power	12 kW
Max Short-Circuit Current	44+44 A
Nominal AC Input Voltage	220-230 V
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Short-Circuit Protection	Yes
Overload Protection	Yes
PV Working Voltage Range	90-500 V
Phase	Single Phase
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Protection	Output Over Current Protection, Output Over Power Protection, Output Short-Circuit Protection, Anti-islanding Protection, GFCI Protection, Arc Fault Circuit Interrupter (AFCI), Insulation Resistor Detection
Rated Apparent Output Power	8 kVA
Rated Output Power	8 kW
Rated PV Input Voltage	380 V
Start-Up Voltage	100 V
Strings per MPPT	2
Surge Rating	2*rated (10s)
Total Harmonic Distortion	<3 %
Transfer Time	10 ms

Mechanical

BMS Communication	RS485, CAN
Communication Interface	RS232, RS485
Display	LCD, LED
Gross Weight	40.5 kg
Installation Style	Wall-Mounted
Monitoring Module	WiFi/GPRS
Net Weight	33.5 kg
Package Dimensions	787 x 547 x 358 mm
Parallel Capability	6
Safety Standard	IEC 62109-1, IEC 62109-2
Topology	Isolated (transformer-based)

Environmental

Cooling	Smart Cooling
IP Rating	IP65
Operating Temperature Range	-25 to 60 (>45 derating) °C

Certifications

IEC 62109-1
IEC 62109-2

Frequently Asked Questions

Up to 12 kW of recommended PV power. Two MPPT trackers take two strings each at 26+26 A, run from 120 to 425 V within a 90-500 V working range capped at 500 V maximum PV voltage, start at 100 V and track at 99.9% efficiency.

40-60 V is the supported battery range, taking Lead-Acid or Li-Ion packs on a single battery input. Charge and discharge each reach 190 A and 8 kW, and the charge algorithm self-adapts to the BMS over RS485 or CAN.

10 ms transfer time, with 8 kW of backup rated output power and a 40 A backup maximum output current. The single-phase output is 220-230 V at 50/60 Hz on L+N+PE wiring, 34.8 A rated and 38.3 A maximum, at under 3% THD.

Up to 6 units in parallel. Each is a wall-mounted IP65 unit of 430 x 654 x 243 mm weighing 33.5 kg net and 40.5 kg gross, smart-cooled for -25 to 60 °C with derating above 45 °C, and monitored over WiFi/GPRS.
