Felicity Solar IVGM HP3G2 three-phase hybrid solar inverter
Felicity MJS

IVGM30KHP3G2

30 kW three-phase high-voltage hybrid solar inverter.

  • Rated AC Output Power: 30kW
  • Battery Voltage Range: 160~800Vdc
11,000 AEDincl. VAT
Full Specifications

Features

Three-phase output

220/380 V through 277/480 V, ten grid configurations.

High-voltage battery

160-800 Vdc across two independent battery inputs.

IP65, -40°C to 60°C

Smart cooling; mounts outdoors.

Overview

The Felicity Solar IVGM30KHP3G2 is a three-phase hybrid inverter rated at 30 kW. It works with a high-voltage LFP battery over a 160-800 Vdc range on two battery inputs, tracks the array from 150 to 850 Vdc, and carries an IP65 enclosure rated from -40°C to 60°C with smart cooling — built for a rooftop or a yard, not a plant room.

Full specifications

Electrical

AC Input/Output Rated Current43. 5 A
Max. AC Input/Output Current47.9A
Max. AC Output Power33kW
Max. Charging Current50+50(A)
Max. DC Input Voltage1000Vdc
Max. Discharging Current50+50(A)
Max. Output Overcurrent Protection (A)(A)
Peak Power (off-grid)(W)power, 10S
Max. Output Overcurrent Protection144 A
Max. AC Input/Output Power33 kW
Rated AC Input/Output Power30 kW
No.of MPP Trackers3
Full Load DC Voltage Range444~850Vdc
Installation StyleWall-mounted
Monitor moduleWiFi/GPRS
Communication with BMSRS485,CAN
Altitude3000 m (> 2000 m derating)
Operating Temperature Range-40 to 60 °C (> 50 °C derating)
Safety EMC / StandardIEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Over Voltage CategoryOVC II(DC), OVC III(AC)
Surge Protection LevelTYPE II(DC), TYPE II(AC)
MPPT Efficiency99.90%
Euro Efficiency97.00%
Max. Efficiency97.60%
DC Injection Current<0.5% In
AC Wiring Mode3L+N+PE
Max. Continuous AC Passthrough (grid to load)200 A
Peak Power (off-grid)1.5 time of rated power, 10S
No.of Strings per MPP Tracker2
Start-up Voltage180 Vd.c.
Number of battery input2
Rated AC Output Power30kW
Max AC Output Power33kW
AC Output Rated Current43.5A
Max. AC Current47.9A
Max. DC Access Power60kW
Max. DC Input Power48kW
Full Load DC Voltage Range444~850Vdc
PV Input Current36+36+36 (A)
Max. PV Isc55+55+55 (A)
Number of MPP Trackers3
Battery TypeLFP (LiFePO4)
Battery Voltage Range160~800Vdc
Max Charging Current50+50 A
Max Discharging Current50+50 A
Number of Battery Input2
Max DC Input Voltage1000Vdc
Min. DC Input Voltage150Vdc
Start-up Voltage180Vdc
Rated DC Input Voltage600Vdc
MPPT Range150~850Vdc
Strings per MPP Tracker2
Rated AC Voltage110V/190V, 115V/200V, 120V/208V, 127V/220V, 133V/230V, 200V/346V, 220V/380V, 230V/400V, 240V/415V, 277V/480V
Rated AC Frequency50 / 60 Hz (45~55Hz / 55~65Hz)
THDi<3% at rated power
Power Factor0.8 leading to 0.8 lagging

Mechanical

Net Weight87.1 kg
Gross Weight107.1 kg
Product Dimension940*582*340 mm
Package Dimension1114*774*469 mm

Environmental

Protection DegreeIP65
Operating Temperature Range-40 to 60°C (>50°C derating)
Humidity0~95% (no condensation)
CoolingSmart Cooling

Certifications

  • CE
  • IEC 62109-1/-2
  • EN 62477-1
  • IEC/EN 61000-6-2/4
