Felicity Solar IVAM8048P1G1 8000 VA Off-Grid Inverter

Felicity Solar IVAM8048P1G1 8kW Single-Phase Off-Grid Solar Inverter

An 8kW off-grid inverter that takes twice its own AC rating in solar: the IVAM8048P1G1 accepts 16kW of PV across two MPPTs and moves 190A in or out of a 48V bank.

Rated Output Power: 8 kW
Max Efficiency: 97.6 %
Max PV Input Power: 16 kW
Battery Voltage Range: 40-60 V

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar IVAM8048P1G1 8kW Single-Phase Off-Grid Solar Inverter features

16kW of PV input across two MPPT trackers

That is twice the 8kW AC rating, carried as 27+27A over 2+2 strings up to a 500V maximum PV voltage.

8kW rated and 8kVA rated apparent output at 230V

Single-phase pure sine wave under 3% total harmonic distortion at 50/60Hz, 34.8A maximum output current.

190A maximum charge and 190A maximum discharge

One battery input spanning 40-60V at 48V nominal, lead-acid or Li-Ion, at up to 8kW of charge and discharge power.

97.6% maximum efficiency over a 90-425V MPPT window

The window narrows to 200-425V at full load, from a 120V start-up voltage and a 370V rated PV input voltage.

IP65 enclosure, 21.4kg net, rated -40°C to 60°C

The unit measures 594 x 385 x 203mm, cools on intelligent air cooling and derates above 45°C, with a DC switch and ground fault current monitoring.

Up to six IVAM8048P1G1 units in parallel

RS485 and CAN carry BMS and system communication, beside an LCD and LED panel and an optional WiFi or LAN monitoring module.

About the Felicity Solar IVAM8048P1G1 8kW Single-Phase Off-Grid Solar Inverter

The Felicity Solar IVAM8048P1G1 is a single-phase off-grid solar inverter rated 8kW and 8kVA at 230V, accepting up to 16kW of PV across two MPPT trackers and charging or discharging a 48V battery bank at up to 190A, with a maximum efficiency of 97.6%. That 16kW PV ceiling is twice the inverter's own AC rating, and it is what separates the IVAM8048P1G1 from other 8kW machines: 27+27A of PV input current over 2+2 strings, a 90-425V MPPT window that narrows to 200-425V at full load, 370V rated PV input, a 120V start-up and 500V maximum PV voltage. One battery input covers 40-60V, lead-acid or Li-Ion, the charge algorithm self-adapting to the pack BMS over RS485 or CAN. Output is a pure sine wave under 3% THD at 50/60Hz, 34.8A maximum, with twice rated power available for 10 seconds and 8kW of backup rated output power. The IP65 case runs from -40°C to 60°C with derating above 45°C on intelligent air cooling, weighs 21.4kg net and measures 594 x 385 x 203mm; six units run in parallel. Certified to IEC 62109-1, EN 62109-1, IEC 62109-2 and EN 62109-2. We are an authorised Felicity Solar distributor; warranty is 2 Years.

Specifications last updated 17 August 2026

Felicity Solar IVAM8048P1G1 8kW Single-Phase Off-Grid Solar Inverter full specifications

Electrical

AC Output Voltage	230 V
AC Wiring Mode	L+N+PE
Backup Rated Output Power	8 kW
Battery Inputs	1
Battery Type	Lead-Acid, Li-Ion
Battery Voltage Range	40-60 V
Charge Algorithm	Self-Adaption to BMS
DC Switch	Yes
Ground Fault Current Monitoring	Yes
MPPT Full-Load Voltage Range	200-425 V
MPPT Trackers	2
MPPT Voltage Range	90-425 V
Max AC Output Power	8 kW
Max AC Pass-Through Current	50 A
Max Charge/Discharge Power	8 kW
Max Charging Current	190 A
Max Discharging Current	190 A
Max Efficiency	97.6 %
Max Output Current	34.8 A
Max PV Input Current	27+27 A
Max PV Input Power	16 kW
Max PV Voltage	500 V
Max Short-Circuit Current	40+40 A
Nominal AC Input Voltage	230 V
Nominal DC Input Voltage	48 V
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Short-Circuit Protection	Yes
Output Voltage Waveform	Pure Sine Wave
Overload Protection	Yes
Overvoltage Category (AC)	III
Overvoltage Category (DC)	II
PV Working Voltage Range	90-500 V
Phase	Single Phase
Protection	DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, Thermal Protection, DC Terminal Insulation Impedance Monitoring, DC Component Monitoring, Ground Fault Current Monitoring, Arc Fault Circuit Interrupter (optional), Power Network Monitoring, Earth Fault Detection, DC Input Switch, Overvoltage Load Drop Protection
Rated Apparent Output Power	8 kVA
Rated Output Power	8 kW
Rated PV Input Voltage	370 V
Start-Up Voltage	120 V
Strings per MPPT	2+2
Surge Protection Level (AC)	II
Surge Rating	2*rated (10s)
Total Harmonic Distortion	<3 %

Mechanical

BMS Communication	RS485, CAN
Communication Interface	RS485, CAN
Display	LCD, LED
Gross Weight	25.4 kg
Monitoring Module	WiFi/LAN (optional)
Net Weight	21.4 kg
Package Dimensions	752 x 507 x 348 mm
Parallel Capability	6
Safety Standard	IEC/EN 62109-1, IEC/EN 62109-2
Topology	Non-Isolated

Environmental

Cooling	Intelligent Air Cooling
IP Rating	IP65
Operating Temperature Range	-40 to 60 (>45 derating) °C

Certifications

IEC 62109-1
EN 62109-1
IEC 62109-2
EN 62109-2

Frequently Asked Questions

16kW of maximum PV input power, twice its own 8kW AC rating, across two MPPT trackers carrying 27+27A on 2+2 strings. Maximum PV voltage is 500V and rated PV input voltage is 370V, with tracking starting at 120V over a 90-425V window that narrows to 200-425V at full load.

48V nominal, over a 40-60V working range on a single battery input. Lead-acid and Li-Ion are both supported at up to 190A charge and 190A discharge, or 8kW of charge and discharge power, and the charge algorithm self-adapts to the pack BMS over RS485 or CAN.

8kW rated output power and 8kVA rated apparent output power at 230V single phase, with 34.8A maximum output current on a pure sine wave under 3% THD. Surge capability is twice rated power for 10 seconds, backup rated output power is 8kW, and six units can run in parallel.

IP65, with an operating range of -40°C to 60°C and derating above 45°C on intelligent air cooling. The unit itself measures 594 x 385 x 203mm and weighs 21.4kg net, while the shipping carton is 752 x 507 x 348mm at 25.4kg gross. Warranty is 2 Years.
