Felicity IVAM8048P1G1 8000 VA Off-Grid Inverter

The Felicity IVAM8048P1G1 is an off-grid inverter with specifications as published by the manufacturer.

Battery Type: Lead-acid or Lithium-ion
Battery Voltage Range(V): 40~60
PV Input Voltage Range(V): 90~500

1 AEDTTC

Aperçu

The Felicity IVAM8048P1G1 is an off-grid inverter with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the IVAM8048P1G1.

Spécifications complètes

Caractéristiques électriques

Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range(V)	40~60
PV Input Voltage Range(V)	90~500
MPPT Voltage Range(V)	90~425
Full Load MPPT Voltage Range(V)	200~425
Max. Operating PV Input Current(A)	27+27
Max. Input Short-Circuit Current(A)	40+40
No. of MPP Trackers/No. of Strings MPP Tracker	2/2+2
Max. AC Output Current(A)	34.8
Rated Output Frequency	50Hz/60Hz
Output Voltage Waveform	Pure Sine Wave
Total Current Harmonic Distortion THDi	<3%
Rated Input Frequency	50Hz/60Hz
Max. Charging Current(A)	190
Max. Discharging Current(A)	190
Number of Battery Input	1
Max. PV access power(W)	16000
Max. PV Input Power(W)	12800
Max. PV Input Voltage(V)	500
Start-up Voltage(V)	120
Rated PV Input Voltage(V)	370
Rated AC Output Power(VA/W)	8000
Max. AC Output Power(VA/W)	8000
Peak Power(W)	2 times of rated power, 10s
Rated Output Voltage(V)	230
Max. Input Power to Battery (W)	8000
Rated Input Voltage(V)	230
Grid Input Current(A)	50
Generator Input Current(A)	50
