Felicity Solar IVEM8048-II 8000VA Off-Grid Inverter

Felicity Solar IVEM8048-II 8kW Single-Phase Off-Grid Solar Inverter

An 8 kW single-phase off-grid inverter that pairs 5+5 kW of PV input with a 150 A charge ceiling, so the IVEM8048-II fills a 48 V bank as hard from the AC input as it does from the array.

Rated Output Power: 8 kW
Max Efficiency: 93 %
Max PV Input Power: 5+5 kW
Battery Voltage Range: 42-63 V

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar IVEM8048-II 8kW Single-Phase Off-Grid Solar Inverter features

5+5 kW of PV input across a 90-450 V MPPT window

Two solar inputs rated 5 kW each carry 20+20 A of current up to a 500 V maximum PV voltage, with tracking that starts at 100 V.

150 A maximum charge current, and 150 A of it from AC

A 42-63 V battery window refills at the same 150 A ceiling whether the energy arrives from the array or from the AC input.

8 kW backup output, 8 kVA rated, single phase at 230 V

A pure sine wave at 50/60 Hz, regulated to within 5%, with the IVEM8048-II surging to twice its rated output for 5 s.

50 ms transfer time on a 90-280 V AC input range

The IVEM8048-II rides an input as low as 90 V and as high as 280 V, disconnects at 90 V and hands its 8 kW of load to the battery in 50 ms.

One battery input at 48 V nominal, up to 6 IVEM8048-II units in parallel

AGM, Flooded, Li-Ion and Self-Defined banks charge at up to 150 A, 56.4 V boost and 54 V float, with RS485 to the BMS, an LCD and built-in WiFi.

23.7 kg net, 25.6 kg gross, 712 x 582 x 259 mm packed

A high-frequency, IP21 chassis on intelligent air cooling for -10 to 50 °C service, certified to IEC 62109-1, IEC 62109-2 and IEC 63027.

About the Felicity Solar IVEM8048-II 8kW Single-Phase Off-Grid Solar Inverter

The Felicity Solar IVEM8048-II is an 8 kW single-phase off-grid inverter. It takes 5+5 kW of solar across a 90-450 V MPPT range, charges a 48 V bank at up to 150 A from the array or the AC input, and holds the load on a 230 V pure sine wave with a 50 ms transfer time. Charging headroom is the figure that defines this model: 150 A maximum charge current, matched by 150 A maximum AC charge current, into a 42-63 V battery window. The single tracker starts at 100 V, works to 450 V and tolerates 500 V maximum PV voltage on 20+20 A of input current. Boost charging holds 56.4 V, float settles at 54 V for AGM, Flooded, Li-Ion and Self-Defined banks, and RS485 carries the BMS link beside an LCD and built-in WiFi. Surge is twice the rated output for 5 s, regulation stays within 5%, and 6 units run in parallel. The high-frequency chassis is 23.7 kg net and 25.6 kg gross in a 712 x 582 x 259 mm carton, certified to IEC 62109-1, IEC 62109-2 and IEC 63027. Warranty is 2 Years. We are the authorised Felicity Solar distributor.

Specifications last updated 17 August 2026

Felicity Solar IVEM8048-II 8kW Single-Phase Off-Grid Solar Inverter full specifications

Electrical

AC Output Voltage	230 V
AC Wiring Mode	L+N+PE
Backup Rated Output Power	8 kW
Battery Inputs	1
Battery Type	AGM, Flooded, Li-Ion, Self-Defined
Battery Voltage Range	42-63 V
Bulk Charging Voltage	56.4 V
Charge Algorithm	Three-Stage: Boost CC, Boost CV, Float
Float Charging Voltage	54 V
High Frequency Disconnect	65 Hz
High Frequency Reconnect	63 Hz
High Line Disconnect Voltage	280 V
High Line Reconnect Voltage	270 V
Input Voltage Range	90-280 V
Input Voltage Range (UPS Mode)	170-280 V
Low Frequency Disconnect	40 Hz
Low Line Disconnect (Appliance Mode)	90 V
Low Line Disconnect (UPS Mode)	170 V
Low Line Reconnect (Appliance Mode)	100 V
Low Line Reconnect (UPS Mode)	180 V
MPPT Trackers	1
MPPT Voltage Range	90-450 V
Max AC Charge Current	150 A
Max AC Input Voltage	280 V
Max AC Pass-Through Current	63 A
Max Charging Current	150 A
Max Efficiency	93 %
Max PV Input Current	20+20 A
Max PV Input Power	5+5 kW
Max PV Voltage	500 V
Max Solar Charging Current	150 A
Motor Start Capable	Yes
Nominal AC Input Voltage	230 V
Nominal DC Input Voltage	48 V
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Short-Circuit Protection	Yes
Output Voltage Regulation	5 %
Output Voltage Waveform	Pure Sine Wave
Overload Protection	Yes
Overload Trip Time (>105% Load)	10.5 s
Overload Trip Time (>120% Load)	7.5 s
Overload Trip Time (>150% Load)	5.5 s
Overload Trip Time (>200% Load)	0.2 s
PV Working Voltage Range	90-450 V
Pass-Through Without Battery	Yes
Phase	Single Phase
Protection	Overload Protection, Over Temperature Protection, Short Circuit Protection
Rated Apparent Output Power	8 kVA
Rated Output Power	8 kW
Start-Up Voltage	100 V
Strings per MPPT	2
Surge Rating	2*rated (5s)
Transfer Time	50 ms

Mechanical

BMS Communication	RS485
Display	LCD
Gross Weight	25.6 kg
Monitoring Module	Built-In WiFi
Net Weight	23.7 kg
Package Dimensions	712 x 582 x 259 mm
Parallel Capability	6
Safety Standard	IEC 62109-1, IEC 62109-2, IEC 63027
Topology	High-Frequency

Environmental

Cooling	Intelligent Air Cooling
IP Rating	IP21
Operating Temperature Range	-10 to 50 °C
Storage Temperature	-15 to 60 °C

Certifications

IEC 62109-1
IEC 62109-2
IEC 63027

Frequently Asked Questions

5+5 kW of PV input, carrying 20+20 A of maximum input current up to a 500 V maximum PV voltage. The single MPPT tracker works from 90 V to 450 V and starts at 100 V, so a string has to reach 100 V before the IVEM8048-II begins harvesting.

150 A is the maximum charge current, and the maximum AC charge current is 150 A as well, so a 48 V nominal bank on a 42-63 V window fills at the same ceiling from an AC source as it does from the array. Boost charging holds 56.4 V and float settles at 54 V.

1 battery input accepts AGM, Flooded, Li-Ion and Self-Defined banks at 48 V nominal, talking to the BMS over RS485, and up to 6 IVEM8048-II units can be run in parallel. An LCD and built-in WiFi report the state of the system.

2 Years. The IVEM8048-II is certified to IEC 62109-1, IEC 62109-2 and IEC 63027, rated IP21, and carries overload protection, over temperature protection and short circuit protection, with intelligent air cooling for service from -10 to 50 °C. We are the authorised Felicity Solar distributor.
