Felicity IVAM10048P1G1 10000 VA Off-Grid Inverter
The Felicity IVAM10048P1G1 is an off-grid inverter with specifications as published by the manufacturer.
- Battery Type: Lead-acid or Lithium-ion
- Battery Voltage Range(V): 40-60
- PV Input Voltage Range(V): 90-500
1 AEDincl. VAT
Overview
The Felicity IVAM10048P1G1 is an off-grid inverter with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the IVAM10048P1G1.
Full specifications
Electrical
| Battery Type | Lead-acid or Lithium-ion |
|---|---|
| Battery Voltage Range(V) | 40-60 |
| PV Input Voltage Range(V) | 90-500 |
| MPPT Voltage Range(V) | 90-425 |
| Rated Output Frequency | 50Hz/60Hz |
| Output Voltage Waveform | Pure Sine Wave |
| Rated Input Frequency | 50Hz/60Hz |
| AC Output Overvoltage Protection | Yes |
| AC Output Short Circuit Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| DC Polarity Reverse Connection Protection | Yes |
| Thermal Protection | Yes |
| DC Terminal Insulation Impedance Monitoring | Yes |
| Power Network Monitoring | Yes |
| Overvoltage Load Drop Protection | Yes |
| Surge Protection Level | TYPE II(DC), TYPE II (AC) |
| Communication Interface | RS485, CAN |
| Monitor Mode | WIFI/LAN (Optional) |
| Over Voltage Category | OVC II (DC), OVC III (AC) |
| Max. Charging Current/Max. Discharging Current(A) | 210 |
| Max. PV Access Power(W) | 20000 |
| Max. PV Input Power (W) | 16000 |
| Full Load MPPT Voltage Range(V) | 200-425 |
| Rated PV Input Voltage(V) | 370 |
| Max. Operating PV Input Current(A) | 32+32 |
| Max. Input Short-Circuit Current(A) | 48+48 |
| No. of MPP Trackers/No. of Strings MPP Tracker | 2/2+2 |
| Rated AC Output Power(VA/W) | 10000 |
| Max. AC Output Power(VA/W) | 10000 |
| Max. AC Output Current(A) | 43.5 |
| Max. Input Power to Battery (W) | 10000 |
| Generator Input Current(A) | 550 |
Mechanical
| Display | LCD+LED |
|---|
Environmental
| Operating Temperature Range | -40 to +60°C, >45°C Derating |
|---|
