Felicity Solar Felicity IVGM25KHP3G3 25 kVA Hybrid Inverter
Felicity MJS

Felicity IVGM25KHP3G3 25 kVA Hybrid Inverter

The Felicity IVGM25KHP3G3 is a hybrid inverter with specifications as published by the manufacturer.

  • Battery Type: LFP (LiFePO4)
  • Battery Voltage Range: 160~700Vdc
  • Max. Charging Current: 50(A)
1 AEDincl. VAT
Full Specifications

Overview

The Felicity IVGM25KHP3G3 is a hybrid inverter with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the IVGM25KHP3G3.

Full specifications

Electrical

Battery TypeLFP (LiFePO4)
Battery Voltage Range160~700Vdc
Max. Charging Current50(A)
Max. Discharging Current50(A)
Max. DC Access Power50kW
Max. DC Input Power40kW
Max. DC Input Voltage1000Vdc
Min. DC Input Voltage150Vdc
Start-up Voltage200Vdc
Rated DC Input Voltage600Vdc
MPPT Range200~850Vdc
Full Load DC Voltage Range666-850Vdc
PV Input Current30+30(A)
Max. PV Isc39+39(A)
No.of Strings Per MPP Tracker2+2
Rated AC Input/Output Power25kW
Max. AC Input/Output Apparent Power27.5kVA
AC Input/Output Rated Current36.3A
Max. AC Current39.8A
Peak Power(off-grid) (W)1.5times of
Rated AC Voltage220/380,230/400 Vac (-20%~+15%)
AC Wiring Mode3L+N+PE
Rated AC Frequency50/60 Hz (45~55 Hz/55~65 Hz)
THDi<3% (At
Power Factor0.8( leading) to 0.8( lagging)
DC Injection Current<0.5% In
Monitor ModuleWiFi/4G

Mechanical

Net Weight41.4KG
Gross Weight47.4KG
Product Dimension642*445*237.5MM
Package Dimension784*563*367MM
Installation StyleWall-mounted

Environmental

Protection DegreeIP66
Operating Temperature Range-40 to 60°C(>45°C Derating)
Humidity0~95% (No Condensation)

Certifications

  • IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
