Felicity IVGM125KHP3G1 125 kW Hybrid Inverter
The Felicity IVGM125KHP3G1 is a hybrid inverter with specifications as published by the manufacturer.
- Battery Type: LFP (LiFePO4)
- Battery Voltage Range: 160~950Vd.c.
- Max. Charging Current: 120+120(A)
1 AEDincl. VAT
Overview
The Felicity IVGM125KHP3G1 is a hybrid inverter with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the IVGM125KHP3G1.
Full specifications
Electrical
| Battery Type | LFP (LiFePO4) |
|---|---|
| Battery Voltage Range | 160~950Vd.c. |
| Max. Charging Current | 120+120(A) |
| Max. Discharging Current | 120+120(A) |
| Max. DC Input Power | 250kW |
| Max. DC Input Voltage | 1000Vd.c. |
| Start-up Voltage | 180Vd.c. |
| Rated DC Input Voltage | 600Vd.c. |
| MPPT Range | 150~950Vd.c. |
| Full Load DC Voltage Range | 555-950Vd.c. |
| PV Input Current | 10x45(A) |
| Max. PV Isc | 10x68(A) |
| Rated AC Input/Output Power | 125kW |
| Max. AC Input/Output Power | 137kVA |
| AC Input/Output Rated Current | 181.2A |
| Max. AC Input/Output Current | 198.6A |
| Rated AC Voltage | 220/380,230/400 Vac (-20%~+15%) |
| AC Wiring Mode | 3L+N+PE |
| Rated AC Frequency | 50/60 Hz (45~55 Hz/55-65 Hz) |
| THDi | <3% (At |
| Power Factor | 0.8( leading) to 0.8( lagging) |
| DC Injection Current | <0.5% In |
| Over Voltage Category | OVC II (DC), OVC III(AC) |
| Inverter Topology | Non-isolated |
| Parallel Compatible | Up to 12 in parallel |
| Monitor Module | WIFI/Bluetooth/4G/LAN(optional) |
Mechanical
| Installation Style | Wall-mounted |
|---|---|
| Net Weight (KG) | 155.5KG |
| Gross Weight (KG) | 198KG |
| Product Dimension (MM) | 1271*810*364MM |
| Package Dimension (MM) | 1410*960*646MM |
Environmental
| Protection Degree | IP66 |
|---|---|
| Operating Temperature Range | -40 to 60 °C (> 45 °C derating) |
| Humidity | 0-100% (No condensation) |
Certifications
- IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
