Felicity Solar IVGM100KHP3G1 100kW Three-Phase Hybrid Solar Inverter

A three-phase hybrid inverter rated 100kW and 100kVA, the IVGM100KHP3G1 peaks at 110kVA and harvests up to 200kW of PV through 8 MPPT trackers.

Rated Output Power: 100 kW
Max Apparent Power: 110 kVA
Max Efficiency: 97.6 %
Max PV Input Power: 200 kW

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar IVGM100KHP3G1 100kW Three-Phase Hybrid Solar Inverter features

100kW rated output and 110kVA maximum apparent power

the IVGM100KHP3G1 is rated 100kVA apparent and withstands a 1.5*rated surge for 10s

200kW of maximum PV input across 8 MPPT trackers

each tracker takes 45A, at up to 1000V PV inside a 150-850V tracking window

Two battery inputs over a 160-1000V LFP range

charging and discharging at 120+120A, with BMS communication on RS485 and CAN

97.6% maximum efficiency and harmonic distortion below 3%

transfer to the 100kW backup output takes 0ms at 220-230V per phase

IP66 wall-mounted cabinet of 156kg net and 200kg gross

measuring 1271 x 814.5 x 379.5 mm and rated from -40 to 60°C up to 4000m

Up to 12 units in parallel, monitored over WiFi, Bluetooth, 4G or LAN

the IVGM100KHP3G1 carries a 2 Years warranty and reports on RS232 and RS485

About the Felicity Solar IVGM100KHP3G1 100kW Three-Phase Hybrid Solar Inverter

The Felicity Solar IVGM100KHP3G1 is a three-phase hybrid solar inverter rated at 100kW and 100kVA, with 110kVA maximum apparent power, 200kW of maximum PV input across 8 MPPT trackers, a 160-1000V battery voltage range, 97.6% maximum efficiency and a 2 Years warranty. Each tracker accepts 45A and up to 1000V, tracking from 150V to 850V after a 180V start-up. The AC side wires as 3L+N+PE at 220-230V per phase and 380-400V line to line, draws up to 159.4A and delivers up to 159.4A behind 270A output overcurrent protection, with harmonic distortion below 3% and a power factor adjustable from 0.8 leading to 0.8 lagging. Two battery inputs charge and discharge LFP packs at 120+120A, and transfer to the 100kW backup output takes 0ms. The IP66 wall-mounted cabinet measures 1271 x 814.5 x 379.5 mm, weighs 156kg net and 200kg gross, runs from -40 to 60°C and up to 4000m, and takes up to 12 units in parallel. We are an authorised Felicity Solar distributor.

Specifications last updated 17 August 2026

Felicity Solar IVGM100KHP3G1 100kW Three-Phase Hybrid Solar Inverter full specifications

Electrical

AC Output Line Voltage	380-400 V
AC Output Voltage	220-230 V
AC Rated Output Current	145 A
AC Wiring Mode	3L+N+PE
Backup Rated Output Power	100 kW
Battery Inputs	2
Battery Type	LFP
Battery Voltage Range	160-1000 V
Charge Algorithm	Self-Adaption to BMS
Grid Frequency Range (50 Hz)	45-55 Hz
Grid Frequency Range (60 Hz)	55-65 Hz
Grid Regulation	IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4110
Ground Fault Current Monitoring	Yes
Input Voltage Range	184-264.5 V
MPPT Full-Load Voltage Range	444-850 V
MPPT Trackers	8
MPPT Voltage Range	150-850 V
Max AC Input Current	159.4 A
Max AC Pass-Through Current	270 A
Max Apparent Power	110 kVA
Max Charging Current	120+120 A
Max Discharging Current	120+120 A
Max Efficiency	97.6 %
Max Output Current	159.4 A
Max Output Overcurrent Protection	270 A
Max PV Input Current	45+45+45+45+45+45+45+45 A
Max PV Input Power	200 kW
Max PV Voltage	1000 V
Max Short-Circuit Current	68+68+68+68+68+68+68+68 A
Nominal AC Input Line Voltage	380-400 V
Nominal AC Input Voltage	220-230 V
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Short-Circuit Protection	Yes
Overload Protection	Yes
Overvoltage Category (AC)	III
Overvoltage Category (DC)	II
Phase	Three Phase
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Protection	PV Input Lightning Protection, PV String Input Reverse Polarity Protection, Battery Input Lightning Protection, Battery Input Reverse Polarity Protection, DC Component Detection, Insulation Resistor Detection, Residual Current Monitoring Unit, Arc Fault Monitoring (optional), Output Over Current Protection, Output Shorted Protection, Output Over Voltage Protection, Remaining Current (RCD) Monitoring, Overheat Protection, Anti-islanding Protection, AC Output Lightning Protection
Rated Apparent Output Power	100 kVA
Rated Output Power	100 kW
Rated PV Input Voltage	600 V
Start-Up Voltage	180 V
Strings per MPPT	2
Surge Protection Level (AC)	III
Surge Rating	1.5*rated (10s)
Total Harmonic Distortion	<3 %
Transfer Time	0 ms

Mechanical

BMS Communication	RS485, CAN
Communication Interface	RS232, RS485
Display	LCD, LED
Gross Weight	200 kg
Installation Style	Wall-Mounted
Monitoring Module	WiFi/Bluetooth/4G/LAN
Net Weight	156 kg
Package Dimensions	1410 x 960 x 646 mm
Parallel Capability	12
Safety Standard	IEC/EN 62109-1, IEC/EN 62109-2
Topology	Non-Isolated

Environmental

Cooling	Smart Cooling
IP Rating	IP66
Operating Altitude	4000 m
Operating Temperature Range	-40 to 60 (>45 derating) °C
Relative Humidity	0-100 (non-condensing) %

Certifications

IEC 62109-1
EN 62109-1
IEC 62109-2
EN 62109-2

Frequently Asked Questions

100kW rated output power, rated at 100kVA apparent, with 110kVA maximum apparent power and a 1.5*rated surge for 10s. Backup rated output power is also 100kW, delivered at 220-230V per phase and 380-400V line to line.

200kW of maximum PV input power across 8 MPPT trackers, each accepting 45A, at a maximum PV voltage of 1000V. Tracking runs from 150V to 850V, begins at a 180V start-up voltage, and peak efficiency is 97.6%.

LFP batteries across a 160-1000V range, on two battery inputs charging and discharging at 120+120A. The charge algorithm self-adapts to the BMS, which communicates over RS485 and CAN.

2 Years warranty. Safety follows IEC 62109-1, EN 62109-1, IEC 62109-2 and EN 62109-2, and grid connection follows IEC 61727, IEC 62116, EN 50549, CEI 0-21, NRS 097, UNE 217002, G99 and VDE-AR-N 4110.
