Felicity IVGM6KLP1G2 6 kW Hybrid Inverter
The Felicity IVGM6KLP1G2 is a hybrid inverter with specifications as published by the manufacturer.
- Battery Voltage Range(V): 40V~60V
- Max.Charging Current(A): 135A
- Max.Discharging Current(A): 135A
1 AEDincl. VAT
Overview
The Felicity IVGM6KLP1G2 is a hybrid inverter with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the IVGM6KLP1G2.
Full specifications
Electrical
| Battery Voltage Range(V) | 40V~60V |
|---|---|
| Max.Charging Current(A) | 135A |
| Max.Discharging Current(A) | 135A |
| Max. PV Access Power(W) | 12000W |
| Max PV Input Power(W) | 9600W |
| Max PV Input Voltage(V) | 500V |
| Start-up Voltage(V) | 125V |
| MPPT Voltage Range(V) | 150V-425V |
| Rated Pv Input Voltage(V) | 370V |
| Max Input Short-Circuit Current(A) | 27+27 |
| Max Operating PV Input Current(A) | 18+18 |
| No.of MPP Trackers/No.of StringPer MPP Tracker | 2/1+1 |
| Rated Ac Input/Output Current(A) | 27.3/26.1 |
| Max. AC Input/Output Current(A) | 30/28.7 |
| Rated Input/Output Voltage/Range(V) | 220V/230 0.85Un-1.1 Un |
| Grid Connection Form | L+N+PE |
| Rated Input/Output Grid Frequency/Range | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz |
| Total Current Harmonic Distortion THDi | <3% (of |
| DC Injection Current | <0.5%In |
| Max.Efficiency | 97.6% |
| Euro Efficiency | 96.5% |
| MPPT Efficiency | >99% |
| Inverter Topology | Non-Isolated |
| Over Voltage Category | OVC II (DC), OVC III (AC) |
Mechanical
| Net Weight(KG) | 19.8KG |
|---|---|
| Gross Weight(KG) | 23KG |
| Product Dimension (MM) | 470*376*250.75MM |
| Package Dimension (MM) | 578*454*348MM |
Environmental
| Operating Temperature Range | -40°C~+60°C, >45°C Derating |
|---|---|
| Permissible Ambient Humidity | 0-100% |
| Permissible Altitude | 2000m |
| Noise | <30dB |
| Ingress Protection (IP) Rating | IP65 |
| Type of cooling | Natural cooling |
Certifications
- IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 ME
