Felicity Solar IVEM12048-11 12000VA Off-Grid Inverter

Felicity Solar IVEM12048-11 12kW Single-Phase Off-Grid Solar Inverter

A 12 kVA single-phase off-grid inverter for 48 V systems: two PV inputs at 7.5+7.5 kW and 27+27 A, a 90-450 V MPPT window, 240 A charging, and a 26.8 kg high-frequency chassis with LCD and built-in WiFi.

Rated Output Power: 12 kW
Max Efficiency: 93 %
Max PV Input Power: 7.5+7.5 kW
Battery Voltage Range: 42-63 V

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar IVEM12048-11 12kW Single-Phase Off-Grid Solar Inverter features

7.5+7.5 kW of PV input power

Two PV inputs carrying 27+27 A feed one MPPT that works from 90 to 450 V, up to a 500 V maximum PV voltage.

240 A maximum charging current

AC charging reaches the same 240 A, holding 56.4 V boost and 54 V float across a 42-63 V bank at 48 V nominal.

12 kVA rated, 12 kW backup power

Delivered as a pure sine wave at 230 V single phase, 50/60 Hz on L+N+PE, regulated to 5% with 2*rated (5s) surge.

50 ms transfer on a 90-280 V input

The AC input holds from 90 V to 280 V with a 100 V start-up voltage, behind overload, over-temperature and short-circuit protection.

26.8 kg net, 28.7 kg gross

Ships in a 726 x 594 x 258 mm carton; the IP21 chassis air-cools intelligently from -10 to 50 °C and stores from -15 to 60 °C.

6 units in parallel, 93% efficiency

A high-frequency design with LCD, built-in WiFi and RS485 BMS communication, certified to IEC 62109-1 and IEC 62109-2.

About the Felicity Solar IVEM12048-11 12kW Single-Phase Off-Grid Solar Inverter

The Felicity Solar IVEM12048-11 is a 12 kVA single-phase off-grid solar inverter for a 48 V battery bank. It takes 7.5+7.5 kW of PV at 27+27 A, charges at up to 240 A from solar or AC, delivers 12 kW of backup rated power at 230 V, and weighs 26.8 kg net. That 7.5+7.5 kW of PV input is the figure that sets the -11 apart; it feeds one MPPT working from 90 to 450 V, up to a 500 V maximum PV voltage. Charging is three-stage, 56.4 V boost and 54 V float across a 42-63 V bank, and the 240 A ceiling holds from the array or from the 90-280 V AC input, which transfers in 50 ms. Output is a pure sine wave at 230 V, 50/60 Hz on L+N+PE, regulated to 5%, with 2*rated (5s) surge and 93% maximum efficiency. The IP21 high-frequency chassis weighs 26.8 kg net, ships at 28.7 kg in a 726 x 594 x 258 mm carton, parallels to 6 units and is certified to IEC 62109-1 and IEC 62109-2. We are the authorised Felicity Solar distributor and supply it with a 2 Years warranty.

Specifications last updated 17 August 2026

Felicity Solar IVEM12048-11 12kW Single-Phase Off-Grid Solar Inverter full specifications

Electrical

AC Output Voltage	230 V
AC Wiring Mode	L+N+PE
Backup Rated Output Power	12 kW
Battery Inputs	1
Battery Type	AGM, Flooded, Li-Ion, Self-Defined
Battery Voltage Range	42-63 V
Bulk Charging Voltage	56.4 V
Charge Algorithm	Three-Stage: Boost CC, Boost CV, Float
Float Charging Voltage	54 V
High Frequency Disconnect	65 Hz
High Frequency Reconnect	63 Hz
High Line Disconnect Voltage	280 V
High Line Reconnect Voltage	270 V
Input Voltage Range	90-280 V
Input Voltage Range (UPS Mode)	170-280 V
Low Frequency Disconnect	40 Hz
Low Line Disconnect (Appliance Mode)	90 V
Low Line Disconnect (UPS Mode)	170 V
Low Line Reconnect (Appliance Mode)	100 V
Low Line Reconnect (UPS Mode)	180 V
MPPT Trackers	1
MPPT Voltage Range	90-450 V
Max AC Charge Current	240 A
Max AC Input Voltage	280 V
Max AC Pass-Through Current	63 A
Max Charging Current	240 A
Max Efficiency	93 %
Max PV Input Current	27+27 A
Max PV Input Power	7.5+7.5 kW
Max PV Voltage	500 V
Max Solar Charging Current	240 A
Motor Start Capable	Yes
Nominal AC Input Voltage	230 V
Nominal DC Input Voltage	48 V
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Output Short-Circuit Protection	Yes
Output Voltage Regulation	5 %
Output Voltage Waveform	Pure Sine Wave
Overload Protection	Yes
Overload Trip Time (>105% Load)	10.5 s
Overload Trip Time (>120% Load)	7.5 s
Overload Trip Time (>150% Load)	5.5 s
Overload Trip Time (>200% Load)	0.2 s
PV Working Voltage Range	90-450 V
Pass-Through Without Battery	Yes
Phase	Single Phase
Protection	Overload Protection, Over Temperature Protection, Short Circuit Protection
Rated Apparent Output Power	12 kVA
Rated Output Power	12 kW
Start-Up Voltage	100 V
Strings per MPPT	2
Surge Rating	2*rated (5s)
Transfer Time	50 ms

Mechanical

BMS Communication	RS485
Display	LCD
Gross Weight	28.7 kg
Monitoring Module	Built-In WiFi
Net Weight	26.8 kg
Package Dimensions	726 x 594 x 258 mm
Parallel Capability	6
Safety Standard	IEC 62109-1, IEC 62109-2
Topology	High-Frequency

Environmental

Cooling	Intelligent Air Cooling
IP Rating	IP21
Operating Temperature Range	-10 to 50 °C
Storage Temperature	-15 to 60 °C

Certifications

IEC 62109-1
IEC 62109-2

Frequently Asked Questions

7.5+7.5 kW is the maximum PV input power of the IVEM12048-11, drawn through 27+27 A of PV input current. The single MPPT works across a 90-450 V window up to a 500 V maximum PV voltage, and start-up voltage is 100 V.

240 A is the maximum charging current, and AC charging reaches the same 240 A. The three-stage charger holds 56.4 V boost and 54 V float across a 42-63 V window at 48 V nominal, supports AGM, Flooded, Li-Ion and Self-Defined batteries on one battery input, and reaches the BMS over RS485.

12 kVA rated apparent power and 12 kW of backup rated power, as a pure sine wave at 230 V single phase, 50/60 Hz on L+N+PE, regulated to 5%. Surge is 2*rated (5s), transfer takes 50 ms when the 90-280 V AC input drops, and maximum efficiency is 93%.

26.8 kg net and 28.7 kg gross, in a 726 x 594 x 258 mm package. The IP21 high-frequency chassis uses intelligent air cooling, runs from -10 to 50 °C and stores from -15 to 60 °C, so it belongs indoors in a ventilated space, and up to 6 units run in parallel. We are the authorised Felicity Solar distributor and supply it with a 2 Years warranty.
