Felicity Solar IVAM12048P1G1 12000 VA Off-Grid Inverter

Felicity Solar IVAM12048P1G1 12kW Single-Phase Off-Grid Solar Inverter

The IVAM12048P1G1 puts 12kW and 12kVA on a 230V single-phase output at 52.2A, draws up to 66A of AC input current with 60A from a generator, and charges a 48V bank at 250A.

  • Rated Output Power: 12 kW
  • Max Apparent Power: 12 kVA
  • Max Efficiency: 97.6 %
  • Max PV Input Power: 24 kW
AED 1incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

Felicity Solar IVAM12048P1G1 12kW Single-Phase Off-Grid Solar Inverter features

66A maximum AC input current with 60A of AC pass-through

A separate row rates the generator input at 60A maximum, all behind a nominal 230V AC input at 50/60Hz.

250A maximum charging and 250A maximum discharging current

12kW of maximum charge and discharge power into one 48V battery input spanning 40-60V, lead-acid or Li-Ion.

12kW rated output power and 12kVA rated apparent output power

52.2A maximum output current at 230V single phase, pure sine wave, twice rated power for 10 seconds and 12kW of backup rated output power.

24kW of maximum PV input power on two MPPT trackers

2+2 strings at 32+32A with 48+48A of short-circuit current, up to 500V, from a 370V rated PV input voltage.

97.6% maximum efficiency with a 90-425V tracking range

Full-load tracking is 200-425V, the PV working voltage range is 90-500V and the unit starts up at 120V.

IP65 enclosure, 594 x 385 x 203mm, 21.4kg net, six in parallel

The 752 x 507 x 348mm carton weighs 25.4kg gross; intelligent air cooling covers -40°C to 60°C with derating above 45°C.

About the Felicity Solar IVAM12048P1G1 12kW Single-Phase Off-Grid Solar Inverter

The Felicity Solar IVAM12048P1G1 is a 12kW and 12kVA single-phase off-grid solar inverter for 48V battery banks, rated at 52.2A maximum output current on 230V and 50/60Hz, charging and discharging at up to 250A, and accepting 24kW of maximum PV input power on two MPPT trackers at 97.6% maximum efficiency. Its inputs are rated separately: 66A of maximum AC input current, 60A of AC pass-through current and 60A of maximum generator input current, all at a nominal 230V. Solar arrives as 32+32A over 2+2 strings with 48+48A of short-circuit current, tracked between 90V and 425V, or 200-425V at full load, from a 120V start-up to a 500V maximum PV voltage. The single battery input works between 40V and 60V on lead-acid or Li-Ion at 12kW of maximum charge and discharge power, the charge algorithm self-adapting to the pack BMS over RS485 or CAN; backup rated output power is likewise 12kW. Its IP65 case measures 594 x 385 x 203mm at 21.4kg net, six units parallel, certified to IEC 62109-1, EN 62109-1, IEC 62109-2 and EN 62109-2. We are an authorised Felicity Solar distributor and supply the IVAM12048P1G1 from our own stock. The warranty is 2 Years.

Specifications last updated 17 August 2026

Felicity Solar IVAM12048P1G1 12kW Single-Phase Off-Grid Solar Inverter full specifications

Electrical

AC Output Voltage230 V
AC Wiring ModeL+N+PE
Backup Rated Output Power12 kW
Battery Inputs1
Battery TypeLead-Acid, Li-Ion
Battery Voltage Range40-60 V
Charge AlgorithmSelf-Adaption to BMS
DC SwitchYes
Ground Fault Current MonitoringYes
MPPT Full-Load Voltage Range200-425 V
MPPT Trackers2
MPPT Voltage Range90-425 V
Max AC Input Current66 A
Max AC Output Power12 kW
Max AC Pass-Through Current60 A
Max Apparent Power12 kVA
Max Charge/Discharge Power12 kW
Max Charging Current250 A
Max Discharging Current250 A
Max Efficiency97.6 %
Max Generator Input Current60 A
Max Output Current52.2 A
Max PV Access Power24 kW
Max PV Input Current32+32 A
Max PV Input Power24 kW
Max PV Voltage500 V
Max Short-Circuit Current48+48 A
Nominal AC Input Voltage230 V
Nominal DC Input Voltage48 V
Nominal Input Frequency50/60 Hz
Output Frequency50/60 Hz
Output Short-Circuit ProtectionYes
Output Voltage WaveformPure Sine Wave
Overload ProtectionYes
Overvoltage Category (AC)III
Overvoltage Category (DC)II
PV Working Voltage Range90-500 V
PhaseSingle Phase
ProtectionDC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, Thermal Protection, DC Terminal Insulation Impedance Monitoring, DC Component Monitoring, Ground Fault Current Monitoring, Arc Fault Circuit Interrupter (optional), Power Network Monitoring, Earth Fault Detection, DC Input Switch, Overvoltage Load Drop Protection
Rated Apparent Output Power12 kVA
Rated Output Power12 kW
Rated PV Input Voltage370 V
Start-Up Voltage120 V
Strings per MPPT2+2
Surge Protection Level (AC)II
Surge Rating2*rated (10s)

Mechanical

BMS CommunicationRS485, CAN
Communication InterfaceRS485, CAN
DisplayLCD, LED
Gross Weight25.4 kg
Monitoring ModuleWiFi/LAN (optional)
Net Weight21.4 kg
Package Dimensions752 x 507 x 348 mm
Parallel Capability6
Safety StandardIEC/EN 62109-1, IEC/EN 62109-2
TopologyNon-Isolated

Environmental

CoolingIntelligent Air Cooling
IP RatingIP65
Operating Temperature Range-40 to 60 (>45 derating) °C

Certifications

  • IEC 62109-1
  • EN 62109-1
  • IEC 62109-2
  • EN 62109-2
