Felicity Solar X-RAY-BDM2250W 2.25kW Single-Phase Off-Grid Solar Inverter

Four panels, four trackers: the X-RAY-BDM2250W gives every input its own MPPT, 750 W and 20 A up to 60 V, and returns 2.25 kW at 230 V with under 5% THD.

Rated Output Power: 2.25 kW
Phase: Single Phase
MPPT Trackers: 4
AC Output Voltage: 230 V

AED 735incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar X-RAY-BDM2250W 2.25kW Single-Phase Off-Grid Solar Inverter features

2.25 kW rated output at 230 V

the X-RAY-BDM2250W delivers 9.78 A on a single phase, wired L+N+PE

Four independent MPPTs, 750 W per input

one string on each tracker, 20 A and up to 60 V per module

22-55 V MPPT window at 99.9% efficiency

every input tracks its own panel across the full range

IP66/IP67 enclosure with GFDI and surge protection

ground fault current monitoring runs on all four inputs

-40°C to 65°C operating range, naturally cooled

6 kg in a 320 x 240 x 35 mm body

Built-in WiFi monitoring, no dongle to add

output holds a power factor above 0.99 and THD below 5% at 50/60 Hz

About the Felicity Solar X-RAY-BDM2250W 2.25kW Single-Phase Off-Grid Solar Inverter

The Felicity Solar X-RAY-BDM2250W is a 2.25 kW single-phase microinverter with four independent MPPT trackers, one string on each, accepting 750 W and 20 A per input at a maximum PV voltage of 60 V and returning 230 V AC at 9.78 A. MPPT efficiency is 99.9% across a 22-55 V tracking window. Because each of the four inputs tracks its own module, a shaded or soiled panel does not drag the other three down with it. The AC side is wired L+N+PE at 50/60 Hz, holds a power factor above 0.99 and keeps total harmonic distortion below 5%. Ground fault current monitoring runs continuously alongside GFDI and surge protection. The sealed IP66/IP67 enclosure is naturally cooled, weighs 6 kg, measures 320 x 240 x 35 mm and is rated from -40°C to 65°C. Monitoring is built-in WiFi, so there is no separate dongle to buy. We are an authorised Felicity Solar distributor, and the X-RAY-BDM2250W carries a 2 Years warranty.

Specifications last updated 23 March 2026

Felicity Solar X-RAY-BDM2250W 2.25kW Single-Phase Off-Grid Solar Inverter full specifications

Electrical

AC Output Voltage	230 V
AC Rated Output Current	9.78 A
AC Wiring Mode	L+N+PE
Ground Fault Current Monitoring	Yes
MPPT Efficiency	99.9 %
MPPT Trackers	4
MPPT Voltage Range	22-55 V
Max PV Input Current	20+20+20+20 A
Max PV Voltage	60 V
Max Recommended PV Power	0.75+0.75+0.75+0.75 kW
Nominal Input Frequency	50/60 Hz
Output Frequency	50/60 Hz
Phase	Single Phase
Power Factor	>0.99
Protection	GFDI, Surge Protection
Rated Output Power	2.25 kW
Strings per MPPT	1
Total Harmonic Distortion	<5 %

Mechanical

Monitoring Module	Built-In WiFi
Net Weight	6 kg

Environmental

Cooling	Nature
IP Rating	IP66/IP67
Operating Temperature Range	-40 to 65 °C

Frequently Asked Questions

Four. The X-RAY-BDM2250W has four MPPT trackers with one string on each, and every input takes up to 750 W and 20 A at a maximum PV voltage of 60 V, tracked across a 22-55 V window.

2.25 kW. The output is single phase at 230 V and 9.78 A, wired L+N+PE at 50/60 Hz, with a power factor above 0.99 and total harmonic distortion below 5%.

IP66/IP67 is its enclosure rating, and it is rated to operate from -40°C to 65°C on natural cooling. The unit weighs 6 kg and measures 320 x 240 x 35 mm.

Built-in WiFi is the monitoring module, so no separate dongle is needed. GFDI, surge protection and continuous ground fault current monitoring guard the four inputs, and the X-RAY-BDM2250W carries a 2 Years warranty.
