Felicity FLA48500 25kWh LiFePO4 Battery Pack
The Felicity FLA48500 is a lifepo4 battery pack with 25kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated.
- Nominal Energy: 25kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48500 is a lifepo4 battery pack with 25kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48500.
Full specifications
Electrical
| Nominal Energy | 25kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Recommend Charge/Discharge Power | <10000W |
| Maximum Charge/Discharge Current (15s) | 300A |
| Maximum Charge/Discharge Power(15s) | 15000W |
| Depth of Discharge(DOD) | ≥95% |
| Scalability | Max.15 pcs in Parallel(375kWh) |
| Cycle Life | >6,000 Cycles |
| Protection | Built-in Smart BMS, Breaker, Fuse |
| Communication | RS485/CAN |
Mechanical
| Display | LCD+LED |
|---|---|
| Installation Style | Floor-Mounted |
| Product Weight | 218KG |
| Package Weight | 248KG |
| Product Dimension | 718X380X990MM |
| Package Dimension | 825X498X1162MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3, CE-EMC, IEC 62619
- 7 Years
Troubleshooting & error codes
Looking up an error code on this FelicityESS FLA48500? Browse the full list of codes for this device, with the cause and recommended fix for each.
