Felicity MJS
Felicity FLA48460TG2-EU 23.5kWh Battery
The Felicity FLA48460TG2-EU is a battery with 23.5kWh of usable storage, a 51.2V nominal bus, > 6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD,70%EOL) rated.
- Nominal Energy: 23.5kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48460TG2-EU is a battery with 23.5kWh of usable storage, a 51.2V nominal bus, > 6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD,70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48460TG2-EU.
Full specifications
Electrical
| Nominal Energy | 23.5kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 250A |
| Peak Charge/Discharge Current(15s) | 500A |
| Max. Charge/Discharge Power | 12,500W |
| Scalability | Max. 15 pcs in Parallel(352.5kWh) |
| Depth of Discharge (DOD) | >95% |
| Cycle Life | > 6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD,70%EOL) |
Mechanical
| Product Weight | 186.5KG |
|---|---|
| Package Weight | 220KG |
| Product Dimension | 570X250X980MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
