FL-OPzV-1000AH-2V
- Voltage Per Unit:2V
- Capacity:1000Ah @10hr-rate to 1.80V per cell @25°C
AED 300
Buy Now — FL-OPzV-1000AH-2V
Felicity MJS
Felicity FLA48500TG2 25kWh LiFePO4 Battery Pack
The Felicity FLA48500TG2 is a lifepo4 battery pack with 25kWh of usable storage, a 51.2V nominal bus, >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated.
- Nominal Energy: 25kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48500TG2 is a lifepo4 battery pack with 25kWh of usable storage, a 51.2V nominal bus, >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48500TG2.
Full specifications
Electrical
| Nominal Energy | 25kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 250A |
| Peak Charge/Discharge Current (15s) | 500A |
| Max. Charge/Discharge Power | 12,500W |
| Scalability | Max. 15 pcs in Parallel(375kWh) |
| Depth of Discharge (DOD) | ≥95% |
| Cycle Life | >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) |
Mechanical
| Product Weight | 186.5KG |
|---|---|
| Package Weight | 219.5KG |
| Product Dimension | 570X250X980MM |
| Package Dimension | 1135X690X465MM ME |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
Troubleshooting & error codes
Looking up an error code on this FelicityESS FLA48500? Browse the full list of codes for this device, with the cause and recommended fix for each.
