Felicity FLA48460-EU 23.5kWh LiFePO4 Battery Pack
The Felicity FLA48460-EU is a lifepo4 battery pack with 23.5kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated.
- Nominal Energy: 23.5kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48460-EU is a lifepo4 battery pack with 23.5kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48460-EU.
Full specifications
Electrical
| Nominal Energy | 23.5kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 200A |
| Peak Charge/Discharge Current (15s) | 300A |
| Max. Charge/Discharge Power(15s) | 10,000W |
| Depth of Discharge(DOD) | ≥95% |
| Scalability | Max.15 pcs in Parallel(354kWh) |
| Cycle Life | >6,000 Cycles |
Mechanical
| Product Weight | 226KG |
|---|---|
| Package Weight | 256KG |
| Product Dimension | 718X380X990MM |
Environmental
| Protection Degree | IP21 |
|---|
