Felicity MJS
Felicity FLA48350TG2 17.5kWh LiFePO4 Battery Pack
The Felicity FLA48350TG2 is a lifepo4 battery pack with 17.5kWh of usable storage, a 51.2V nominal bus, 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) rated.
- Nominal Energy: 17.5kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48350TG2 is a lifepo4 battery pack with 17.5kWh of usable storage, a 51.2V nominal bus, 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48350TG2.
Full specifications
Electrical
| Nominal Energy | 17.5kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 175A |
| Peak Charge/Discharge Current (15s) | 300A |
| Max. Charge/Discharge Power | 8,750W |
| Scalability | Max. 15 pcs in Parallel(262.5kWh) |
| Depth of Discharge(DOD) | ≥95% |
| Protection | Built-in Smart BMS, Breaker, Fuse |
| Communication | RS485/CAN |
| Cycle Life | 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) |
Mechanical
| Installation | Floor-Mounted |
|---|---|
| Product Weight | 121.5KG |
| Package Weight | 143.5KG |
| Product Dimension | 435X880X247MM |
| Package Dimension | 960X555X450MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
