Felicity Solar SCCM8048-III Solar Charge Controller

Felicity Solar SCCM8048-III Solar Charge Controller

The Felicity SCCM8048-III is a solar charge controller with specifications as published by the manufacturer.

  • PV Start-up Voltage: 20V
  • Nominal System Voltage: 12V, 24V, 48V (Auto Detection)
  • Temperature Compensation Coefficient: -5 mV/°C/cell (25°Cref.)
AED 1incl. VAT

In stock

Full SpecificationsDownload datasheet (PDF)

About the Felicity Solar SCCM8048-III Solar Charge Controller

The Felicity SCCM8048-III is a solar charge controller with specifications as published by the manufacturer. Every figure on this page is taken from the manufacturer's datasheet for the SCCM8048-III. We are an authorised Felicity Solar distributor and supply the SCCM8048-III from our own stock, with technical support before and after the sale.

Specifications last updated 17 August 2026

Felicity Solar SCCM8048-III Solar Charge Controller full specifications

Electrical

PV Start-up Voltage20V
Nominal System Voltage12V, 24V, 48V (Auto Detection)
Temperature Compensation Coefficient-5 mV/°C/cell (25°Cref.)
Maximum Charge Current80 A
Nominal System Voltage12-48 V
MPPT Voltage Range18-125 V
Maximum PV Input Voltage145 V
Maximum PV Input Power1100-4400 W
Maximum Efficiency98 %
Charging Algorithm3-Step
Supported Battery TypesAGM, Gel, Flooded, Lithium, User-Defined
CommunicationRS485, CAN, MODBUS, Bluetooth, WiFi
Ingress ProtectionIP20
Surge Protection4500 W/port
InstallationWall-Mounted
Net Weight3.5 kg

Environmental

Ambient Temperature Range0°C to +55 °C
Storage Temperature-25 °C to +75 °C
Humidity0%-90%RH (No Condensing)

Troubleshooting & error codes

Looking up an error code on this FelicityESS SCCM3024-III? Browse the full list of codes for this device, with the cause and recommended fix for each.

View error codes for this device →
