Felicity FLA48200 10kWh LiFePO4 Battery Pack
The Felicity FLA48200 is a lifepo4 battery pack with 10kWh of usable storage, a 51.2V nominal bus, >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated.
- Scalability: Max. 15 pcs in Parallel(76.8kWh) in Parallel(150kWh)
- Depth of Discharge (DOD): ≥95%
- Cycle Life: >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL)
1 AEDincl. VAT
Overview
The Felicity FLA48200 is a lifepo4 battery pack with 10kWh of usable storage, a 51.2V nominal bus, >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48200.
Full specifications
Electrical
| Scalability | Max. 15 pcs in Parallel(76.8kWh) in Parallel(150kWh) |
|---|---|
| Depth of Discharge (DOD) | ≥95% |
| Cycle Life | >6000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) |
| Nominal Energy | 10kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Recommend Charge/Discharge Power | <6,000W |
| Maximum Charge/Discharge Current (15s) | 150A |
| Maximum Charge/Discharge Power(15s) | 7,500W |
Mechanical
| Product Weight | 68KG |
|---|---|
| Package Weight | 88KG |
| Product Dimension | 735X433X188MM |
| Package Dimension | 849X550X362MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- IEC 62619 CB
