Felicity Solar FLA48230 11.8kWh LiFePO4 Battery Pack

Felicity Solar FLA48230 51.2V 11.8kWh LiFePO4 Battery

A 230 Ah LiFePO4 battery rated 11.8 kWh at 51.2 V, with 150 A continuous current, a 200 A peak for 15 seconds and a built-in smart BMS, breaker and fuse.

Nominal Energy: 11.8 kWh
Nominal Capacity: 230 Ah
Nominal Voltage: 51.2 V
Cycle Life: ≥6000

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar FLA48230 51.2V 11.8kWh LiFePO4 Battery features

11.8 kWh at 51.2 V

The FLA48230 stores 11.8 kWh of nominal energy on a 51.2 V bus, drawn from a 230 Ah LiFePO4 pack.

176.6 kWh across 15 units

Up to 15 FLA48230 units run in parallel, for a maximum system capacity of 176.6 kWh.

150 A continuous, 200 A peak

150 A of continuous charge and discharge current, also the recommended figure, rising to a 200 A peak for 15 seconds.

10000 W for 15 seconds

Peak charge and discharge power reaches 10000 W for 15 seconds, with 7500 W recommended for continuous duty.

≥6000 cycles, ≥95% depth of discharge

Cycle life is rated at ≥6000 cycles, and depth of discharge is a separate rating of ≥95%.

92 kg, 783 x 274 x 450 mm, IP21

The FLA48230 weighs 92 kg, measures 783 x 274 x 450 mm, is rated IP21, mounts on a wall or the floor and links over CAN or RS485.

About the Felicity Solar FLA48230 51.2V 11.8kWh LiFePO4 Battery

The Felicity Solar FLA48230 is a 51.2 V LiFePO4 battery rated 230 Ah and 11.8 kWh of nominal energy, with a depth of discharge of ≥95%, a cycle life of ≥6000 cycles and a built-in smart BMS. Up to 15 units run in parallel for a maximum system capacity of 176.6 kWh. Continuous charge and discharge current is 150 A, also the recommended figure, for 7500 W of recommended power, with a 200 A or 10000 W peak held for 15 seconds. The operating window runs 44.8 V to 57.6 V, cutting off at 44.8 V and charging to no more than 57.6 V. CAN and RS485 ports carry state of charge to the inverter, while an LCD screen and LED indicators report it locally. The cabinet weighs 92 kg, measures 783 x 274 x 450 mm and is rated IP21, wall-mounted or floor-mounted. Charge it from 0 to 55 °C and discharge it from -20 to 55 °C. Protection is a built-in smart BMS with a breaker and a fuse; the pack is certified to UN38.3 and CB. We are an authorised Felicity Solar distributor, and the FLA48230 carries a 5 Years warranty.

Specifications last updated 17 August 2026

Felicity Solar FLA48230 51.2V 11.8kWh LiFePO4 Battery full specifications

Electrical

Battery Type	LiFePO4
Cut-Off Voltage	44.8 V
Cycle Life	≥6000
Depth of Discharge	≥95 %
Max Charge/Discharge Power (15 s)	10000 W
Max Charging Voltage	57.6 V
Max Continuous Charge/Discharge Current	150 A
Max Parallel Units	15
Max System Capacity	176.6 kWh
Nominal Capacity	230 Ah
Nominal Energy	11.8 kWh
Nominal Voltage	51.2 V
Operating Voltage	44.8-57.6 V
Peak Charge/Discharge Current (15 s)	200 A
Protection	Built-in Smart BMS, Breaker, Fuse
Recommended Charge/Discharge Current	150 A
Recommended Charge/Discharge Power	7500 W

Mechanical

Communication	CAN, RS485
Display Type	LCD, LED
Installation	Wall-Mounted, Floor-Mounted
Package Dimensions	900 x 450 x 570 mm
Package Weight	115.6 kg

Environmental

Charging Temperature Range	0-55 °C
Discharging Temperature Range	-20 to 55 °C
Protection Degree	IP21

Certifications

UN38.3
CB

Frequently Asked Questions

11.8 kWh of nominal energy at 51.2 V, from a 230 Ah LiFePO4 pack. Depth of discharge is a separate rating of ≥95%, and that is what governs how much of the 11.8 kWh you actually draw.

15 units, for a maximum system capacity of 176.6 kWh. Each unit contributes 11.8 kWh at 51.2 V and coordinates with the rest over CAN or RS485.

150 A continuously, which is also the recommended charge and discharge current, with a 200 A peak for 15 seconds. In power terms that is 7500 W recommended and 10000 W at peak.

≥6000 cycles is the rated cycle life, and the FLA48230 carries a 5 Years warranty. Charge it from 0 to 55 °C and discharge it from -20 to 55 °C, inside the 44.8 V to 57.6 V operating window.
