Felicity Solar FLH96050SG2 102.4V 5.12kWh LiFePO4 Battery

The Felicity Solar FLH96050SG2 is a stacked high-voltage LiFePO4 battery built from 5.12 kWh, 102.4 V modules. Two to six modules give 10.24 to 30.72 kWh of system energy at 204.8 to 614.4 V nominal, of which 9.21 to 27.64 kWh is usable at a 90% depth of discharge. Across that 2 to 6 module range the pack operates between 185.6 V and 691.2 V. Each 50Ah module accepts 50 A maximum continuous charge and discharge current, with 25 A the recommended figure for everyday cycling, over a cycle life rated at 6000 cycles or more. A built-in smart BMS and breaker cover protection, an LED plus LCD touch display reports pack state at the cabinet, and RS485 and CAN ports carry that data out. The IP65 enclosure stacks or floor-mounts and is listed at 600 x 1760 x 385 mm and 357.5 kg, each battery module weighing 57.5 kg net and the control module 12.5 kg net (24.5 kg with its base). Charging runs 0 to +55 C, discharging -20 to +55 C, at 5% to 95% humidity below 2000 m. We are an authorised Felicity Solar distributor and supply the FLH96050SG2 from our own stock.
