Felicity MJS
Felicity FLA48200-P 10.5kWh LiFePO4 Battery Pack
The Felicity FLA48200-P is a lifepo4 battery pack with 10.5kWh of usable storage, a 51.2V nominal bus, 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated.
- Nominal Energy: 10.5kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48200-P is a lifepo4 battery pack with 10.5kWh of usable storage, a 51.2V nominal bus, 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48200-P.
Full specifications
Electrical
| Nominal Energy | 10.5kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Recommend Charge/Discharge Power | <7,500W |
| Maximum Charge/Discharge Current (15s) | 200A |
| Maximum Charge/Discharge Power(15s) | 10,000W |
| Scalability | Max. 15 pcs in Parallel(157.4kWh) |
| Depth of Discharge(DOD) | >95% |
| Cycle Life | 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) |
Mechanical
| Product Weight | 92KG |
|---|---|
| Package Weight | 115.6KG |
| Product Dimension | 783X450X274MM |
| Package Dimension | 900X570X450MM Product Display Compatible Inverter Brands List Os |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- IEC 62619
Troubleshooting & error codes
Looking up an error code on this FelicityESS FLA48200? Browse the full list of codes for this device, with the cause and recommended fix for each.
View error codes for this device →Related Products
