Felicity MJS
Felicity FLA48206WG1-EU 10.5kWh Battery
The Felicity FLA48206WG1-EU is a battery with 10.5kWh of usable storage, a 51.2V nominal bus, >6,000 @25°C rated.
- Battery Type: LiFePO4
- Nominal Energy: 10.5kWh
- Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity FLA48206WG1-EU is a battery with 10.5kWh of usable storage, a 51.2V nominal bus, >6,000 @25°C rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48206WG1-EU.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Energy | 10.5kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Charge/Discharge Power (15s) | Charge 8200W Discharge 8200W |
| Scalability | Max. 15 pcs in Parallel(157.5kWh) |
| Depth of Discharge (DOD) | ≥95% |
| Communication | CAN2.0/RS485/WIFI/Bluetooth |
| Protection | BMS, Fuse, Breaker, MX+OF |
Mechanical
| Product Weight | 87KG |
|---|---|
| Package Weight | 98KG |
| Product Dimension | 787X450X249MM |
| Package Dimension | 900X568X344MM |
Environmental
| Protection Degree | IP21 |
|---|
