Felicity MJS
Felicity FLA48314-PLUS 16kWh LiFePO4 Battery Pack
The Felicity FLA48314-PLUS is a lifepo4 battery pack with 16kWh of usable storage, a 51.2V nominal bus, 8,000 Cycles (25°C +2°C,0.5C/0.5C,90%DOD, 70%EOL) rated.
- Battery Type: LiFePO4
- Nominal Energy: 16kWh
- Nominal Capacity: 314Ah
1 AEDincl. VAT
Overview
The Felicity FLA48314-PLUS is a lifepo4 battery pack with 16kWh of usable storage, a 51.2V nominal bus, 8,000 Cycles (25°C +2°C,0.5C/0.5C,90%DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48314-PLUS.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Energy | 16kWh |
| Nominal Capacity | 314Ah |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8~57.6V |
| Max. Continuous Charge/Discharge Current | 160A |
| Peak Charge/Discharge Current (15s) | 300A |
| Scalability | Max. 32 pcs in Parallel(512kWh) |
| Depth of Discharge (DOD) | >95% |
| Cycle Life | 8,000 Cycles (25°C +2°C,0.5C/0.5C,90%DOD, 70%EOL) |
| Protection | Built-in smart BMS, Breaker, Fuse |
| Communication | RS485/CAN |
Mechanical
| Installation | Floor-Mounted |
|---|---|
| Product Weight | 121KG |
| Package Weight | 143KG |
| Product Dimension | 450X895X235MM |
| Package Dimension | 958X548X440MM |
Environmental
| Working Temperature Range | Discharge: -20°C~+55 °C |
|---|---|
| Storge Temperature Range | 0°C~+35°C |
| Humidity | 5%~95% |
| Altitude | <2000m |
| Protection Degree | IP65 |
Certifications
- 7 Years
- UN38.3
