Felicity MJS
Felicity FLA48314-EU 16kWh LiFePO4 Battery Pack
The Felicity FLA48314-EU is a lifepo4 battery pack with 16kWh of usable storage, a 51.2V nominal bus, 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) rated.
- Battery Type: LiFePO4
- Nominal Energy: 16kWh
- Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity FLA48314-EU is a lifepo4 battery pack with 16kWh of usable storage, a 51.2V nominal bus, 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48314-EU.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Energy | 16kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 160A |
| Peak Charge/Discharge Current(15s) | 300A |
| Max. Charge/Discharge Power(15s) | 8,000W |
| Scalability | Max. 15 pcs in Parallel(240kWh) |
| Depth of Discharge (DOD) | >95% |
| Protection | Built-in smart BMS, Breaker, Fuse |
| Communication | RS485/CAN |
| Cycle Life | 8000 Cycles (25°C±2°C,0.5C/0.5C,90% DOD, 70%EOL) |
Mechanical
| Installation | Floor-Mounted |
|---|---|
| Product Weight | 121.5KG |
| Package Weight | 143.5KG |
| Product Dimension | 435X880X247MM |
| Package Dimension | 960X555X450MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
