Felicity MJS
Felicity FLA48300TG2 15kWh LiFePO4 Battery Pack
The Felicity FLA48300TG2 is a lifepo4 battery pack with 15kWh of usable storage, a 51.2V nominal bus, 118.5KG shipped.
- Communication: CAN
- Nominal Energy: 15kWh
- Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity FLA48300TG2 is a lifepo4 battery pack with 15kWh of usable storage, a 51.2V nominal bus, 118.5KG shipped. Every figure on this page is taken from the manufacturer's datasheet for the FLA48300TG2.
Full specifications
Electrical
| Communication | CAN |
|---|---|
| Nominal Energy | 15kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 160A |
| Peak Charge/Discharge Current(15s) | 23A |
| Max. Charge/Discharge Power | 8,000W |
| Scalability | Max. 15 pcs in Parallel(225kWh) |
| Depth of Discharge (DOD) | >95 |
| Protection | Built-in Smart BMS |
Mechanical
| Installation | Floor- |
|---|---|
| Product Weight | 118.5KG |
| Package Weight | 140.5KG |
| Product Dimension | 435X880X247MM |
| Package Dimension | 960X555X450MM |
