Felicity LPBF48250 12.5kWh LiFePO4 Battery Pack
The Felicity LPBF48250 is a lifepo4 battery pack with 12.5kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated.
- Battery Type: LiFePO4
- Nominal Energy: 12.5kWh
- Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity LPBF48250 is a lifepo4 battery pack with 12.5kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the LPBF48250.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Energy | 12.5kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 48-57.6V |
| Recommend Charge/Discharge Power | <6,000W |
| Maximum Charge/Discharge Current (15s) | 200A |
| Maximum Charge/Discharge Power(15s) | 10,000W |
| Depth of Discharge(DOD) | >95% |
| Scalability | Max. 6 pcs in Parallel (90kWh) |
| Cycle Life | >6,000 Cycles |
| Protection | Built-in Smart BMS, Breaker, Fuse |
| Communication | RS485/CAN |
Mechanical
| Display | LED |
|---|---|
| Installation Style | Floor-Mounted |
| Product Weight | 154KG |
| Package Weight | 177KG |
| Product Dimension | 615x350x955MM |
| Package Dimension | 718x450x1112MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3, CE-EMC IEC 62619
Troubleshooting & error codes
Looking up an error code on this FelicityESS LPBF48250? Browse the full list of codes for this device, with the cause and recommended fix for each.
