Felicity Solar LPBF48100-M 51.2V 5kWh LiFePO4 Battery
At 40 kg in a 507Γ455Γ184 mm case, the LPBF48100-M is the compact end of 5 kWh storage: IP21, wall- or floor-mounted, and six units deep for 30 kWh.
- Nominal Energy: 5kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 48-57.6V
In stock
Felicity Solar LPBF48100-M 51.2V 5kWh LiFePO4 Battery features
About the Felicity Solar LPBF48100-M 51.2V 5kWh LiFePO4 Battery
The Felicity Solar LPBF48100-M stores 5 kWh at 51.2 V nominal, works between 48 V and 57.6 V, and is rated above 6000 cycles with a depth of discharge published separately at β₯95%. Six units in parallel is the stated limit, which the record puts at 30 kWh. Power is quoted twice, for two different durations: under 2500 W is the recommended charge and discharge power, while 5000 W and 100 A are the maxima and they are rated for 15 seconds. The gap between those two numbers is the point of the specification β a steady household draw with headroom for a motor start, rather than continuous high power. The case measures 507Γ455Γ184 mm and the product weighs 40 kg, which is light for the energy it holds; it is rated IP21 and goes on a wall or on the floor. That 40 kg is the product's own weight and not a packaged figure. It carries a UN38.3 certification and a 5 Years warranty. We are an authorised Felicity Solar distributor and supply the LPBF48100-M from our own stock.
Specifications last updated 17 August 2026
Felicity Solar LPBF48100-M 51.2V 5kWh LiFePO4 Battery full specifications
Electrical
| Nominal Energy | 5kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 48-57.6V |
| Recommend Charge/Discharge Power | <2,500W |
| Maximum Charge/Discharge Current(15s) | 100A |
| Maximum Charge/Discharge Power(15s) | 5,000W |
| Depth of Discharge(DOD) | β₯95% |
| Scalability | Max. 6 pcs in Parallel(30kWh) |
| Cycle Life | >6,000 Cycles |
Mechanical
| Installation Style | Wall-Mounted / Floor-Mounted |
|---|---|
| Product Weight | 40KG |
| Package Weight | 44KKG |
| Product Dimension | 507x455x184MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
Troubleshooting & error codes
Looking up an error code on this FelicityESS LPBF48100-M? Browse the full list of codes for this device, with the cause and recommended fix for each.
View error codes for this device βRelated Products
