Felicity Solar FLB48100WG1-H 5.12kWh Battery

Felicity Solar FLB48100WG1-H 5.12kWh Lithium Iron Phosphate Battery

A 100Ah lithium iron phosphate module holding 5.12kWh, rated for >6,000 cycles, wall-mounted or floor-mounted and parallelable to 32 units.

Depth of Discharge (DOD): >95%
Communication: CAN2.0/RS485/WIFI/Bluetooth
Nominal Energy: 5.12kWh

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar FLB48100WG1-H 5.12kWh Lithium Iron Phosphate Battery features

5.12kWh nameplate energy at a 100Ah nominal capacity, with depth of discharge rated at >95%.

Cycle life rated at >6,000, so the FLB48100WG1-H is specified for daily cycling rather than standby duty.

100A of continuous charge and discharge current on the FLB48100WG1-H, rising to a 150A peak sustained for 15 seconds.

Up to 32 units in parallel, taking a single bank to 163.84kWh without changing the module.

Four protection layers sit across the FLB48100WG1-H's 100A current path: a built-in smart BMS, a breaker, a fuse and a Thermal Runaway Management System.

48.5KG net and 53KG packed, in a 650X450X174MM enclosure that is wall-mounted or floor-mounted.

About the Felicity Solar FLB48100WG1-H 5.12kWh Lithium Iron Phosphate Battery

The Felicity Solar FLB48100WG1-H is a 5.12kWh lithium iron phosphate battery with a 100Ah nominal capacity, a depth of discharge rated at >95%, a cycle life of >6,000 and headroom to parallel 32 units for 163.84kWh. Continuous charge and discharge current is 100A, peaking at 150A for 15 seconds. Protection is layered rather than bolted on: a built-in smart BMS, a breaker, a fuse and a Thermal Runaway Management System. CAN2.0, RS485, WIFI and Bluetooth are all available for monitoring and system integration. The enclosure measures 650X450X174MM and weighs 48.5KG, 53KG in its packaging, and it is rated for wall-mounted or floor-mounted installation. The working range is -20°C to +55°C for charge and discharge, with storage at 0°C to +35°C, relative humidity from 5% to 95% and altitude below 2,000m. We are the authorised Felicity Solar distributor for this model and supply it with a 5 Years warranty.

Specifications last updated 17 August 2026

Felicity Solar FLB48100WG1-H 5.12kWh Lithium Iron Phosphate Battery full specifications

Electrical

Depth of Discharge (DOD)	>95%
Communication	CAN2.0/RS485/WIFI/Bluetooth
Nominal Energy	5.12kWh
Nominal Capacity	100Ah
Max. Continuous Charge/Discharge Current	100A
Peak Charge/Discharge Current(15s)	150A
Scalability	Max. 32 pcs in Parallel(163.84kWh)
Protection	Built-in smart BMS, Breaker, Fuse, Thermal Runaway Management System
Cycle Life	>6,000
Battery Type	Lithium Iron Phosphate

Mechanical

Installation	Wall-Mounted / Floor-Mounted
Product Weight	48.5KG
Package Weight	53KG
Product Dimension	650X450X174MM

Environmental

Working Temperature Range	Charge/Discharge: -20°C~+55 °C
Storge Temperature Range	0°C~+35°C
Humidity	5%~95%
Altitude	<2,000m
Voltage Protection	Low Voltage Protection in Charging
Current Protection	Over Current Protection in Charging
Working Temperature	-20°C to +55°C

Certifications

UN38.3

Frequently Asked Questions

5.12kWh, drawn from a 100Ah lithium iron phosphate pack whose depth of discharge is rated at >95%, so almost the whole nameplate figure is reachable on each cycle.

>6,000 is the rated cycle life of the FLB48100WG1-H, a figure that describes daily cycling rather than standby service, and we supply the unit with a 5 Years warranty.

100A continuous in both directions, with a 150A peak held for 15 seconds. A built-in smart BMS, a breaker, a fuse and a Thermal Runaway Management System sit across that current path, and CAN2.0, RS485, WIFI and Bluetooth report what the battery is doing.

32 units in parallel, for 163.84kWh in one bank. Each unit measures 650X450X174MM, weighs 48.5KG net and 53KG packed, and can be wall-mounted or floor-mounted, with an operating range of -20°C to +55°C and altitude below 2,000m.
