Felicity FLA48100UG1 5.12kWh LiFePO4 Battery Pack
The Felicity FLA48100UG1 is a lifepo4 battery pack with 5.12kWh of usable storage, a 51.2V nominal bus, 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated.
- Nominal Energy: 5.12kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLA48100UG1 is a lifepo4 battery pack with 5.12kWh of usable storage, a 51.2V nominal bus, 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48100UG1.
Full specifications
Electrical
| Nominal Energy | 5.12kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 100A |
| Peak Charge/Discharge Current (15s) | 125A |
| Max. Charge/Discharge Power | 5,000W |
| Peak Charge/Discharge Power(15s) | 6,250W |
| Depth of Discharge (DOD) | >95% |
| Scalability | Max. 32 pcs in Parallel(163.84kWh) |
| Protection Level | IP21 |
| Cycle Life | 6,000 Cycles (25°C±2°C,0.5C/0.5C,90%DOD, 70%EOL) |
Mechanical
| Display Type | LED |
|---|---|
| Installation | Stacked |
| Net Weight | 43KG |
| Gross Weight | 47KG |
| Product Dimension | 575X483X133MM |
| Package Dimension | 642X542X241MM • 00 C A Ø Ø ☺ NE |
