Felicity Solar FLA24200 25.6V 5kWh LiFePO4 Battery

The Felicity Solar FLA24200 carries 200 Ah of nominal capacity — 5 kWh of nominal energy — at 25.6 V, working across a 22.4-28.8 V window between a 22.4 V cut-off and a 28.8 V maximum charging voltage. Everyday duty is set by a recommended 120 A and 3000 W; the burst rating is 150 A and 3750 W, each over 15 seconds. Fifteen FLA24200 units in parallel reach a maximum system capacity of 75 kWh. Cycle life is rated at 6000 cycles or more, and depth of discharge appears separately at ≥95%, which governs how much of the 5 kWh each cycle draws. The battery weighs 39 kg at 482 × 194 × 433 mm; its carton is a distinct 44 kg at 600 × 282 × 555 mm. A built-in Smart BMS with breaker and fuse protects an IP21 enclosure, wall- or floor-mounted, charging from 0 to 55 °C and discharging from -20 to 55 °C, reporting on an LCD and LED display over CAN and RS485. UN38.3 certification covers the cells, under a 5 Years warranty. We are an authorised Felicity Solar distributor and supply the FLA24200 from our own stock.
