Felicity Solar LPBF12300 3.75kWh LiFePO4 Battery Pack

Felicity Solar LPBF12300 12.8V 3.75kWh LiFePO4 Battery

A floor-mounted 300 Ah LiFePO4 battery: the LPBF12300 holds 3.75 kWh of nominal energy at 12.8 V, runs past 6000 cycles, and reports over CAN and RS485 through a built-in Smart BMS.

Nominal Energy: 3.75 kWh
Nominal Capacity: 300 Ah
Nominal Voltage: 12.8 V
Cycle Life: >6000

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar LPBF12300 12.8V 3.75kWh LiFePO4 Battery features

3.75 kWh of nominal energy

The LPBF12300 carries 300 Ah at a 12.8 V nominal voltage, with a depth of discharge above 95%.

Cycle life beyond 6000 cycles

LiFePO4 chemistry backed by a 5 Years warranty on the LPBF12300.

150 A recommended charge and discharge current

That is 1875 W continuous, with 200 A and 2500 W allowed for 15 s peaks.

Up to 16 units in parallel

Sixteen LPBF12300 batteries reach a maximum system capacity of 60 kWh.

Built-in Smart BMS and fuse

CAN and RS485 report to a compatible inverter, and an LCD with LED indicators shows the same reading at the battery.

34 kg in a 492 x 245 x 381 mm floor-mounted case

Rated IP21, charging from 0-55 °C and discharging from -20 to 55 °C.

About the Felicity Solar LPBF12300 12.8V 3.75kWh LiFePO4 Battery

The Felicity Solar LPBF12300 is a 12.8 V LiFePO4 battery rated 300 Ah, or 3.75 kWh of nominal energy, with a depth of discharge above 95% and a cycle life beyond 6000 cycles. It weighs 34 kg, measures 492 x 245 x 381 mm, stands on the floor and cuts off at 11.2 V. Charging tops out at 14.4 V, so the working window is 11.2-14.4 V. Felicity Solar rates 150 A, or 1875 W, as the recommended continuous charge and discharge current, with 200 A and 2500 W available for 15 s peaks. Sixteen LPBF12300 units can be paralleled to a maximum system capacity of 60 kWh. A built-in Smart BMS and fuse handle protection, while CAN and RS485 carry state of charge to a compatible inverter and an LCD with LED indicators repeats it at the unit. Charge between 0-55 °C and discharge from -20 to 55 °C; the IP21 enclosure is an indoor one. The cells carry UN38.3, packed weight is 38 kg in a 560 x 303 x 450 mm carton, and the warranty is 5 Years. We are an authorised Felicity Solar distributor and supply the LPBF12300 from our own stock.

Specifications last updated 17 August 2026

Felicity Solar LPBF12300 12.8V 3.75kWh LiFePO4 Battery full specifications

Electrical

Battery Type	LiFePO4
Cut-Off Voltage	11.2 V
Cycle Life	>6000
Depth of Discharge	>95 %
Max Charge/Discharge Power (15 s)	2500 W
Max Charging Voltage	14.4 V
Max Parallel Units	16
Max System Capacity	60 kWh
Nominal Capacity	300 Ah
Nominal Energy	3.75 kWh
Nominal Voltage	12.8 V
Operating Voltage	11.2-14.4 V
Peak Charge/Discharge Current (15 s)	200 A
Protection	Built-in Smart BMS, Fuse
Recommended Charge/Discharge Current	150 A
Recommended Charge/Discharge Power	1875 W

Mechanical

Communication	CAN, RS485
Display Type	LCD, LED
Installation	Floor-Mounted
Package Dimensions	560 x 303 x 450 mm
Package Weight	38 kg

Environmental

Charging Temperature Range	0-55 °C
Discharging Temperature Range	-20 to 55 °C
Protection Degree	IP21

Certifications

UN38.3

Frequently Asked Questions

3.75 kWh of nominal energy, which is 300 Ah at a 12.8 V nominal voltage. Depth of discharge is rated above 95%, so the nominal figure is not the usable figure and nearly all of it is drawable.

16. Sixteen LPBF12300 units reach the maximum system capacity of 60 kWh, and they share state of charge over CAN and RS485 from the built-in Smart BMS.

150 A is the recommended continuous charge and discharge current, equal to 1875 W. Peaks of 200 A and 2500 W are allowed for 15 s. Charging voltage tops at 14.4 V and the pack cuts off at 11.2 V, an 11.2-14.4 V working window.

34 kg, measuring 492 x 245 x 381 mm as a floor-mounted unit. Packed for shipping it is 38 kg in a 560 x 303 x 450 mm carton. The enclosure is rated IP21, so it belongs indoors.
