Felicity Solar FLB48280TG1-H 51.2V 14.3kWh Battery
The FLB48280TG1-H is a 51.2V battery holding 14.3kWh of nominal energy, weighing 118kg net in a 450 x 895 x 235mm IP65 housing and moving 150A in either direction.
- Nominal Energy: 14.3kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
In stock
Felicity Solar FLB48280TG1-H 51.2V 14.3kWh Battery features
About the Felicity Solar FLB48280TG1-H 51.2V 14.3kWh Battery
The Felicity Solar FLB48280TG1-H is a 51.2V battery rated at 14.3kWh of nominal energy, charging and discharging at 150A — 7680W in each direction — down to a 95% depth of discharge. It weighs 118kg net, measures 450 x 895 x 235mm and carries an IP65 protection rating. Weight and footprint are what separate this unit from the other 14.3kWh models: 118kg net on its own, 140.5kg gross with packaging, and an envelope 450mm wide by 895mm high by 235mm deep. The electrical window runs from 44.8V to 57.6V, and both charge and discharge are rated from -20°C to 55°C. Protection is layered — BMS, fuse, breaker and MX+OF — behind the IP65 enclosure, an LED display shows working state, and CAN2.0, RS485, WIFI and Bluetooth handle communication. Where one unit is not enough, up to 32 units run in parallel. We are an authorised Felicity Solar distributor, and the FLB48280TG1-H carries a 5 Years warranty.
Specifications last updated 17 August 2026
Felicity Solar FLB48280TG1-H 51.2V 14.3kWh Battery full specifications
Electrical
| Nominal Energy | 14.3kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Charge/Discharge Current | Charge 150A Discharge 150A |
| Max. Charge/Discharge Power | Charge 7680W Discharge 7680W |
| Depth of Discharge(DOD) | 95% |
| Scalability | Up to 32 units in parallel |
| Communication | CAN2.0/RS485/WIFI/Bluetooth |
| Protection Level | IP65 |
| Protection | BMS, Fuse, Breaker, MX+OF |
Mechanical
| Display | LED |
|---|---|
| Net Weight | 118Kg |
| Gross Weight | 140.5Kg |
| Product Dimension | 450X895X235MM |
Environmental
| Operating Temperature | Charge:-20-55°C/Discharge: -20~55 °C |
|---|
