Felicity FLB48280TG1-H 14.3kWh Battery
The Felicity FLB48280TG1-H is a battery with 14.3kWh of usable storage, a 51.2V nominal bus, Charge: 0-55°C/Discharge: -20~55 °C rated.
- Nominal Energy: 14.3kWh
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
1 AEDincl. VAT
Overview
The Felicity FLB48280TG1-H is a battery with 14.3kWh of usable storage, a 51.2V nominal bus, Charge: 0-55°C/Discharge: -20~55 °C rated. Every figure on this page is taken from the manufacturer's datasheet for the FLB48280TG1-H.
Full specifications
Electrical
| Nominal Energy | 14.3kWh |
|---|---|
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8-57.6V |
| Max. Charge/Discharge Current | Charge 150A Discharge 150A |
| Max. Charge/Discharge Power | Charge 7680W Discharge 7680W |
| Depth of Discharge(DOD) | 95% |
| Scalability | Up to 32 units in parallel |
| Communication | CAN2.0/RS485/WIFI/Bluetooth |
| Protection Level | IP65 |
| Protection | BMS, Fuse, Breaker, MX+OF |
Mechanical
| Display | LED |
|---|---|
| Net Weight | 118Kg |
| Gross Weight | 140.5Kg |
| Product Dimension | 450X895X235MM |
Environmental
| Operating Temperature | Charge:-20-55°C/Discharge: -20~55 °C |
|---|
