Felicity Solar FLB48280TG1-AU 14.3kWh Battery

Felicity Solar FLB48280TG1-AU 51.2V 14.3kWh LiFePO4 Battery

A floor-mounted 51.2V LiFePO4 pack, the FLB48280TG1-AU weighs 115Kg net and holds 14.3kWh of nominal energy at a 95% depth of discharge, with 150A of continuous charge and discharge current.

Nominal Energy: 14.3kWh
Battery Type: LiFePO4
Nominal Voltage: 51.2V

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar FLB48280TG1-AU 51.2V 14.3kWh LiFePO4 Battery features

115Kg net weight in a floor-mounted cabinet measuring 895×450×235mm

300A peak charge/discharge current for 15s, above the 150A continuous rating

14.3kWh of nominal energy at 51.2V, with a 95% depth of discharge

7680W of continuous charge power and 7680W of continuous discharge power

Four interfaces on one pack: CAN2.0, RS485, WIFI and Bluetooth, plus an LED display

Charging specified 0~55°C, discharging -20~55°C, and up to 32 units in parallel

About the Felicity Solar FLB48280TG1-AU 51.2V 14.3kWh LiFePO4 Battery

The Felicity Solar FLB48280TG1-AU is a floor-mounted 51.2V LiFePO4 battery rated at 14.3kWh of nominal energy, weighing 115Kg net in a cabinet of 895×450×235mm, with a 95% depth of discharge, 150A of continuous charge and discharge current, and a 300A peak for 15s. Continuous power is 7680W in each direction, and the operating window runs 44.8-57.6V. The 14.3kWh figure is the nominal energy of the cells; how much of it leaves the pack in a cycle is governed by the separate 95% depth-of-discharge row. Charging is specified 0~55°C and discharging -20~55°C. Four interfaces are built in — CAN2.0, RS485, WIFI and Bluetooth — and an LED display reports state at the cabinet itself. Protection is integrated: BMS, Fuse, Breaker and MX+OF. Up to 32 units can be paralleled where one FLB48280TG1-AU is not enough, and the packed shipping weight is 124.5Kg. We are an authorised Felicity Solar distributor, and the FLB48280TG1-AU carries a 5 Years warranty.

Specifications last updated 17 August 2026

Felicity Solar FLB48280TG1-AU 51.2V 14.3kWh LiFePO4 Battery full specifications

Electrical

Nominal Energy	14.3kWh
Battery Type	LiFePO4
Nominal Voltage	51.2V
Operating Voltage	44.8-57.6V
Max. Charge/Discharge Current	Charge 150A Discharge 150A
Max. Charge/Discharge Power	Charge 7680W Discharge 7680W
Depth of Discharge(DOD)	95%
Scalability	Up to 32 units in parallel
Communication	CAN2.0, RS485,WIFI, Bluetooth
Protection	BMS, Fuse, Breaker, MX+OF
Peak Charge/Discharge Current(15s)	300A @ 15s

Mechanical

Display	LED
Installation	Floor-Mounted
Net Weight	115Kg
Gross Weight	124.5Kg
Product Dimension	895×450x235mm
Package Dimension	1013×588×342mm

Environmental

Operating Temperature	Charge 0~55°C Discharge -20~55 °C

Frequently Asked Questions

115Kg net, in a floor-mounted cabinet measuring 895×450×235mm. Packed for transport the unit weighs 124.5Kg in a 1013×588×342mm carton, so plan the delivery route and the floor position before it arrives rather than after.

95% is the published depth of discharge for the FLB48280TG1-AU. The 14.3kWh is the nominal energy of the cells; what the BMS releases in a cycle is governed by that separate depth-of-discharge figure, not by the nominal rating.

300A @ 15s. Continuous charge and discharge are both 150A, which is 7680W in each direction at the 51.2V nominal bus, so short surges are covered without sizing the whole installation around them.

Charge 0~55°C and discharge -20~55°C. The operating voltage window is 44.8-57.6V, and the battery carries a 5 Years warranty. We are an authorised Felicity Solar distributor.
