Felicity MJS
Felicity FLA12171-EU Battery
The Felicity FLA12171-EU is a battery with a 12.8V nominal bus, ≥6,000 Cycles rated.
- Energy: 2.2kWh
- Battery Type: LiFePO4
- Nominal Voltage: 12.8V
1 AEDincl. VAT
Overview
The Felicity FLA12171-EU is a battery with a 12.8V nominal bus, ≥6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA12171-EU.
Full specifications
Electrical
| Energy | 2.2kWh |
|---|---|
| Battery Type | LiFePO4 |
| Nominal Voltage | 12.8V |
| Operating Voltage | 11.2-14.4V |
| Recommend Charge/Discharge Power | $1,500W |
| Maximum Charge/Discharge Current(15s) | 200A |
| Maximum Charge/Discharge Power(15s) | 2,500W |
| Depth of Discharge(DOD) | ≥ 95% |
| Scalability | Up to 16 units in parallel(35.2kWh) |
| Cycle Life | ≥6,000 Cycles |
| Protection | Built-in smart BMS, Fuse |
| Communication | RS485/CAN |
Mechanical
| Display | LCD+LED |
|---|---|
| Installation | Floor-Mounted |
| Net Weight | 15kg |
| Gross Weight | 18kg |
| Product Dimension | 328×248×199mm |
| Package Dimension | 391×310×257mm |
Certifications
- 5 Years
