Felicity FLB24100WG1 2.56kWh Battery
The Felicity FLB24100WG1 is a battery with 2.56kWh of usable storage, a 25.6V nominal bus, ≥ 6000 Cycles(25 rated.
- Battery Type: LiFePO4
- Nominal Voltage: 25.6V
- Operating Voltage: 22.4~28.8V
1 AEDincl. VAT
Overview
The Felicity FLB24100WG1 is a battery with 2.56kWh of usable storage, a 25.6V nominal bus, ≥ 6000 Cycles(25 rated. Every figure on this page is taken from the manufacturer's datasheet for the FLB24100WG1.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Voltage | 25.6V |
| Operating Voltage | 22.4~28.8V |
| Depth of Discharge(DOD) | ≥ 95% |
| Protection | Built- |
| Nominal Energy | 2.56kWh |
| Nominal Capacity | 100Ah |
| Max.continuous charge/Discharge current | 100A |
| Peak Charge/Discharge Current (15s) | 150A |
| Scalability | Up to 32 units in parallel(81.92kWh) |
| Cycle Life | ≥ 6000 Cycles(25 |
Mechanical
| Installation | Wall |
|---|---|
| Product Weight Approximate | 29.3kg |
| Package Weight Approximate | 32.9kg |
| Product Dimension | 540x375x150mm |
| Package Dimension | 642×477×253mm |
Environmental
| Working Temperature Range | Charge: 0°C~+55°C |
|---|---|
| Storge Temperature Range | 0°C~+35°C |
| Humidity | 5%~95% |
| Altitude | ≤ 2000m |
