Felicity Solar LPBF24100-M 2.5kWh LiFePO4 Battery Pack

Felicity Solar LPBF24100-M 25.6V 2.5kWh LiFePO4 Battery

A 22 kg 25.6V LiFePO4 battery holding 2.5 kWh of nominal energy, the LPBF24100-M runs a 60 A recommended charge and discharge current and scales to 15 kWh across 6 parallel units.

Nominal Energy: 2.5 kWh
Nominal Capacity: 100 Ah
Nominal Voltage: 25.6 V
Cycle Life: >6000

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar LPBF24100-M 25.6V 2.5kWh LiFePO4 Battery features

2.5 kWh of nominal energy at 25.6V from a 100 Ah LiFePO4 cell bank

22 kg module measuring 420 x 195 x 341 mm, wall-mounted or floor-mounted

60 A and 1500 W recommended charge and discharge, peaking at 100 A and 2500 W for 15 seconds

Up to 6 units in parallel build a 15 kWh bank on one 24-28.8 V bus

Rated above 6000 cycles, with a depth of discharge above 95%

Built-in smart BMS and fuse, CAN and RS485 communication, LCD and LED indication, IP21 enclosure

About the Felicity Solar LPBF24100-M 25.6V 2.5kWh LiFePO4 Battery

The Felicity Solar LPBF24100-M is a 25.6V LiFePO4 battery module storing 2.5 kWh of nominal energy from a 100 Ah cell bank, weighing 22 kg and measuring 420 x 195 x 341 mm. It is rated for more than 6000 cycles, with a depth of discharge above 95%. Day to day the pack accepts a recommended 60 A charge and discharge current, or 1500 W, and absorbs 100 A and 2500 W bursts for 15 seconds. Its working window runs 24-28.8 V, with charging capped at 28.8 V and a 24 V cut-off, and up to 6 LPBF24100-M units parallel into a single 15 kWh bank. A built-in smart BMS and a fuse handle protection, CAN and RS485 report state of charge to a compatible inverter, and an LCD with LED indicators shows it locally. The IP21 enclosure mounts on a wall or stands on the floor, charging between 0-55 °C and discharging from -20 to 60 °C. Certifications are UN38.3, CE-EMC and IEC 62619. We are an authorised Felicity Solar distributor and supply the LPBF24100-M from our own stock. Warranty: 5 Years.

Specifications last updated 17 August 2026

Felicity Solar LPBF24100-M 25.6V 2.5kWh LiFePO4 Battery full specifications

Electrical

Battery Type	LiFePO4
Cut-Off Voltage	24 V
Cycle Life	>6000
Depth of Discharge	>95 %
Max Charge/Discharge Power (15 s)	2500 W
Max Charging Voltage	28.8 V
Max Parallel Units	6
Max System Capacity	15 kWh
Nominal Capacity	100 Ah
Nominal Energy	2.5 kWh
Nominal Voltage	25.6 V
Operating Voltage	24-28.8 V
Peak Charge/Discharge Current (15 s)	100 A
Protection	Built-in Smart BMS, Fuse
Recommended Charge/Discharge Current	60 A
Recommended Charge/Discharge Power	1500 W

Mechanical

Communication	CAN, RS485
Display Type	LCD, LED
Installation	Wall-Mounted, Floor-Mounted
Package Dimensions	517 x 243 x 433 mm
Package Weight	26 kg

Environmental

Charging Temperature Range	0-55 °C
Discharging Temperature Range	-20 to 60 °C
Protection Degree	IP21

Certifications

UN38.3
CE-EMC
IEC 62619

Frequently Asked Questions

2.5 kWh of nominal energy, drawn from a 100 Ah cell bank at 25.6V nominal. Usable energy follows the rated depth of discharge, which is above 95%.

6 units in parallel, giving a maximum system capacity of 15 kWh on a single 24-28.8 V bus.

60 A is the recommended charge and discharge current, equal to 1500 W. Peaks reach 100 A and 2500 W for 15 seconds, charging is capped at 28.8 V and the cut-off is 24 V.

22 kg, in a 420 x 195 x 341 mm IP21 enclosure that is wall-mounted or floor-mounted. The packed carton is a separate figure: 26 kg and 517 x 243 x 433 mm.
