Felicity FLA24100PG2 2.56kWh LiFePO4 Battery Pack
The Felicity FLA24100PG2 is a lifepo4 battery pack with 2.56kWh of usable storage, a 25.6V nominal bus, >6,000 Cycles rated.
- Nominal Energy: 2.56kWh
- Nominal Voltage: 25.6V
- Operating Voltage: 22.4-28.8V
1 AEDincl. VAT
Overview
The Felicity FLA24100PG2 is a lifepo4 battery pack with 2.56kWh of usable storage, a 25.6V nominal bus, >6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA24100PG2.
Full specifications
Electrical
| Nominal Energy | 2.56kWh |
|---|---|
| Nominal Voltage | 25.6V |
| Operating Voltage | 22.4-28.8V |
| Peak Charge/Discharge Current(15s) | 150A |
| Max.Charge/Discharge Power | 3750W |
| Scalability | Max. 16 pcs in Parallel(40.96kWh) |
| Depth of Discharge (DOD) | >95% |
| Cycle Life | >6,000 Cycles |
Mechanical
| Product Weight | 19.5KG |
|---|---|
| Package Weight | 22KG |
| Product Dimension | 350X306X185MM |
Environmental
| Protection Degree | IP21 |
|---|
