Felicity LPBF48150-P 7.2kWh LiFePO4 Battery Pack
The Felicity LPBF48150-P is a lifepo4 battery pack with 7.2kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated.
- Battery Type: LiFePO4
- Nominal Energy: 7.2kWh
- Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity LPBF48150-P is a lifepo4 battery pack with 7.2kWh of usable storage, a 51.2V nominal bus, >6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the LPBF48150-P.
Full specifications
Electrical
| Battery Type | LiFePO4 |
|---|---|
| Nominal Energy | 7.2kWh |
| Nominal Voltage | 51.2V |
| Operating Voltage | 48-57.6V |
| Recommend Charge/Discharge Power | <3,000W |
| Maximum Charge/Discharge Current (15s) | 120A |
| Maximum Charge/Discharge Power(15s) | 6,000W |
| Cycle Life | >6,000 Cycles |
| Protection | Built-in Smart BMS, Fuse |
Mechanical
| Display | LED |
|---|---|
| Installation Style | Wall-Mounted / Floor-Mounted |
| Product Weight | 54.5KG |
| Package Weight | 59.5KG |
| Product Dimension | 654x425x203MM |
| Package Dimension | 752x527x268MM |
Certifications
- UN38.3 CE-EMC, IEC 62619
- 5 Years
