Felicity FLA24250WG2 6.4kWh LiFePO4 Battery Pack
The Felicity FLA24250WG2 is a lifepo4 battery pack with 6.4kWh of usable storage, a 25.6V nominal bus, ≥6,000 Cycles rated.
- Depth of Discharge (DOD): ≥95%
- Cycle Life: ≥6,000 Cycles
- Nominal Energy: 6.4kWh
1 AEDincl. VAT
Overview
The Felicity FLA24250WG2 is a lifepo4 battery pack with 6.4kWh of usable storage, a 25.6V nominal bus, ≥6,000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA24250WG2.
Full specifications
Electrical
| Depth of Discharge (DOD) | ≥95% |
|---|---|
| Cycle Life | ≥6,000 Cycles |
| Nominal Energy | 6.4kWh |
| Nominal Voltage | 25.6V |
| Operating Voltage | 22.4-28.8V |
| Max. Continuous Charge/Discharge Current | 175A |
| Peak Charge/Discharge Current (15s) | 300A |
| Max. Charge/Discharge Power | 4,480W |
| Scalability | Max. 15 pcs in Parallel (96kWh) |
Mechanical
| Installation | Wall-Mounted / Floor-Mounted |
|---|---|
| Product Weight | 49.5KG |
| Package Weight | 54.5KG |
| Product Dimension | 400X402X275MM |
| Package Dimension | 512X472X333MM |
Environmental
| Protection Degree | IP21 |
|---|
Certifications
- UN38.3
