Deep-cycle gel chemistry
Immobilised electrolyte, no topping up, no spillage.
Felicity MJS
G12V65AH
12 V, 65 Ah deep-cycle gel battery for daily solar cycling.
- Voltage Per Unit: 12 V
- Capacity: 65Ah @10hr-rate to 1.80V per cell @25°C
190 AEDincl. VAT
Features
Overview
The Felicity Solar G12V65AH is a valve-regulated gel battery from the DC (GEL Deep Cycle) series, built for the frequent charge and discharge a solar installation puts a battery through every day. 12 V, 65 Ah Felicity rates the series at 30% more cyclic life than its standby equivalent, and it is equally at home on a solar array, a boat or an RV.
Full specifications
Electrical
| Charge Current | 0.6 |
|---|---|
| Discharge Current | (A) 0.2C |
| Cycle service | 10°C |
| Terminal Voltage (V) | 100% (0.05CAX 20h) |
| Capacity | 65Ah @10hr-rate to 1.80V per cell @25°C |
| Max. Discharge Current | 650A (5 sec) |
| Internal Resistance | Approx. 6.0 mΩ |
| Recommended Maximum Charging Current Limit | 22.5A |
| Cells Per Unit | 6 |
| Battery Type | Lead-acid gel (GEL deep cycle, VRLA) |
| Voltage Per Unit | 12 V |
| Float charging Voltage | 13.6 to 13.8V DC/unit Average at 25°C |
| Equalization and Cycle Service | 14.4 to 14.6V DC/unit Average at 25°C |
| Self Discharge | Less than 3% per month at 25°C; can be stored more than 6 months at 25°C |
| Operating Temperature Range | Discharge: -20°C ~ 60°C; Charge: 0°C ~ 50°C; Storage: -20°C ~ 60°C |
| Normal Operating Temperature Range | 25°C ± 5°C |
Mechanical
| Size (L×W×H) | 350x166x175 mm |
|---|---|
| Weight | 16 kg |
Certifications
- CE
- ISO9001
