Deep cycle battery suitable
for solar energy systems, marine, and RV
Felicity MJS
G12V150AH
Discover the Felicity Solar G12V150AH battery with 6 cells, 12V, and 150Ah capacity at 10hr-rate, ideal for reliable energy storage.
- Voltage Per Unit: 12
- Capacity: 150Ah@10hr-rate
448 AEDincl. VAT
Features
Overview
The Felicity Solar G12V150AH battery is engineered to deliver dependable power with its 6-cell configuration and 12V output. With a capacity of 150Ah at a 10-hour rate, this battery is perfect for various energy storage needs.
Full specifications
Electrical
| Constant Power Discharge Characteristics (W, 25°C) | 45A |
|---|---|
| Constant Power Discharge Characteristics (W, 25°C) | 45A |
| Discharge Current | -0.2Cx2h+14.4-14.7Vx24h,Max. Current 0.3C |
| Cycle service | 10°C |
| Float charging Voltage | 13.6 to 13.8V DC/unit Average at 25°C |
| Voltage Per Unit | 12 |
| Cells Per Unit | 6 |
| Battery Type | Lead-acid gel (GEL deep cycle, VRLA) |
| Capacity | 150Ah@10hr-rate |
| Max. Discharge Current | 1500A(5 sec) |
| Internal Resistance | Approx. 4.2 mΩ |
| Recommended Maximum Charging Current Limit | 45A |
| Operating Temperature Range | Discharge: -20°C to 60°C; Charge: 0°C to 50°C; Storage: -20°C to 60°C |
| Normal Operating Temperature Range | 25°C ± 5°C |
| Equalization And Cycle Service | 14.4 to 14.6V DC/unit Average at 25°C |
| Self Discharge | GEL batteries can be stored for more than 6 months at 25°C. Self-discharge ratio less than 3% per month at 25°C. |
Mechanical
| SIZE | 484x170x241MM |
|---|---|
| Weight | 42.5Kg |
Certifications
- CE
- ISO9001
