Deep cycle battery suitable
for solar energy systems, marine, and RV.
Felicity MJS
G12V100AH
Discover the Felicity Solar G12V100AH battery with 6 cells, 12V, and 100Ah capacity, ideal for efficient energy storage.
- Voltage Per Unit: 12
- Capacity: 100Ah @10hr-rate to 1.80V per cell @25°C
294 AEDincl. VAT
Features
Overview
Introducing the Felicity Solar G12V100AH battery, engineered for optimal performance and reliability. With 6 cells delivering 12 volts and a capacity of 100Ah at a 10-hour rate, this battery is designed to meet your energy storage needs efficiently.
Full specifications
Electrical
| Constant Power Discharge Characteristics (W, 25°C) | 30A |
|---|---|
| Constant Power Discharge Characteristics (W, 25°C) | 30A |
| Discharge Current | 0.2C (A) <1.0C (A) 1.0C |
| Cycle service | 10°C |
| Float charging Voltage | 13.6 to 13.8V DC/unit Average at 25°C |
| Voltage Per Unit | 12 |
| Cells Per Unit | 6 |
| Battery Type | Lead-acid gel (GEL deep cycle, VRLA) |
| Capacity | 100Ah @10hr-rate to 1.80V per cell @25°C |
| Max. Discharge Current | 1000A(5 sec) |
| Internal Resistance | Approx. 5.0 mΩ |
| Recommended Maximum Charging Current Limit | 30A |
| Operating Temperature Range | Discharge: -20°C – 60°C; Charge: 0°C – 50°C; Storage: -20°C – 60°C |
| Normal Operating Temperature Range | 25°C ± 5°C |
| Equalization And Cycle Service | 14.4 to 14.6V DC/unit Average at 25°C |
| Self Discharge | GEL batteries can be stored for more than 6 months at 25°C. Self-discharge ratio less than 3% per month at 25°C. |
Mechanical
| SIZE | 330x171x218MM |
|---|
Certifications
- CE
- ISO9001
