Felicity FLS48100SG1 LiFePO4 Battery Pack
The Felicity FLS48100SG1 is a lifepo4 battery pack with > 6000 Cycles rated, 46KG Battery Module shipped.
- Module Nominal Energy: 5.12kWh
- Module Nominal Capacity: 100Ah
- Module Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity FLS48100SG1 is a lifepo4 battery pack with > 6000 Cycles rated, 46KG Battery Module shipped. Every figure on this page is taken from the manufacturer's datasheet for the FLS48100SG1.
Full specifications
Electrical
| Module Nominal Energy | 5.12kWh |
|---|---|
| Module Nominal Capacity | 100Ah |
| Module Nominal Voltage | 51.2V |
| System Nominal Energy | 5.12kWh 10.24kWh 15.36kWh 20.48kWh 25.6kWh 30.72kWh 35.84kWh 40.96kWh |
| System Nominal Voltage | 51.2V |
| System Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 60A 120A 180A 240A 300A 360A 400A 400A |
| Peak Charge/Discharge Current (155) | 100A 200A 300A 400A 500A 600A 700A 800A |
| Scalability | Max. 8 pcs in Parallel |
| Depth of Discharge(DOD) | ≥95% |
| Protection Level | IP21 |
| Cycle Life | > 6000 Cycles |
Mechanical
| Product Weight Approximate | 46KG Battery Module |
|---|---|
| Control Module Package Weight Approximate | 60KG FLS48100SCG1 |
| Package Dimension | 712X562X333 MM |
Environmental
| Working Temperature Range | Discharge: -20°C~55 °C |
|---|---|
| Storge Temperature Range | 0°C~+35°C |
| Altitude | <2000M |
Certifications
- UN38.3, CE-EMC, IEC 62619, CB
