FL-OPzV-1000AH-2V
- Voltage Per Unit:2V
- Capacity:1000Ah @10hr-rate to 1.80V per cell @25°C
AED 300
Buy Now — FL-OPzV-1000AH-2V
Felicity MJS
Felicity FLS48050SMG1 LiFePO4 Battery Pack
The Felicity FLS48050SMG1 is a lifepo4 battery pack with > 6000 Cycles rated, 31KG shipped.
- Module Nominal Energy: 2.56kWh
- Module Nominal Capacity: 50Ah
- Module Nominal Voltage: 51.2V
1 AEDincl. VAT
Overview
The Felicity FLS48050SMG1 is a lifepo4 battery pack with > 6000 Cycles rated, 31KG shipped. Every figure on this page is taken from the manufacturer's datasheet for the FLS48050SMG1.
Full specifications
Electrical
| Module Nominal Energy | 2.56kWh |
|---|---|
| Module Nominal Capacity | 50Ah |
| Module Nominal Voltage | 51.2V |
| System Operating Voltage | 44.8-57.6V |
| Depth of Discharge (DOD) | ≥95% |
| Cycle Life | > 6000 Cycles |
| Battery Designation | 150/102/[1P16S]M/-10+50/95 |
Mechanical
| Installation | Floor-Mounted |
|---|---|
| Product Weight Approximate | 31KG |
| Package Dimension | 642X462X337 MM |
Environmental
| Working Temperature Range | Charge: 0°C~55 °C Discharge: -20°C~55 °C |
|---|---|
| Storge Temperature Range | 0°C~+35°C |
| Altitude | <2000m |
Certifications
- , CE-EMC, IEC 62619
