Felicity MJS
Felicity FLA48280-EU 14.3kWh LiFePO4 Battery Pack
The Felicity FLA48280-EU is a lifepo4 battery pack with 14.3kWh of usable storage, a 51.2V nominal bus, > 6000 Cycles rated.
- Nominal Voltage: 51.2V
- Operating Voltage: 44.8-57.6V
- Max. Continuous Charge/Discharge Current: 150A
1 AEDincl. VAT
Overview
The Felicity FLA48280-EU is a lifepo4 battery pack with 14.3kWh of usable storage, a 51.2V nominal bus, > 6000 Cycles rated. Every figure on this page is taken from the manufacturer's datasheet for the FLA48280-EU.
Full specifications
Electrical
| Nominal Voltage | 51.2V |
|---|---|
| Operating Voltage | 44.8-57.6V |
| Max. Continuous Charge/Discharge Current | 150A |
| Depth of Discharge (DOD) | ≥95% |
| Cycle Life | > 6000 Cycles |
| Nominal Energy | 14.3kWh |
| Nominal Capacity | 280Ah |
| Peak Charge/Discharge Current (15s) | 300A |
| Max. Charge/Discharge Power (15s) | 7,500W |
| Scalability | Max. 15 pcs in Parallel(214.5kWh) |
Mechanical
| Display Type | LCD |
|---|---|
| Product Weight | 135KG |
| Package Weight | 160KG |
| Product Dimension | 480X1100X300MM |
Environmental
| Protection Degree | IP21 |
|---|---|
| Working Temperature Range | Discharge: -20°C~55 °C |
| Storge Temperature Range | 0°C~+35°C |
| Humidity | 5%~95% |
Certifications
- UN38.3
