Conversion efficiency up to
23.2%
Felicity MJS
GK-1-72HTBD-580M
Discover the Felicity Solar GK-1-72HTBD-580M solar panel with 580W power and 51.47V open circuit voltage for efficient energy solutions.
- Maximum Power Current (Imp): 13.62A
- Rated Maximum Power (Pmax): 580W
696 AEDincl. VAT
Features
Overview
Introducing the Felicity Solar GK-1-72HTBD-580M, a high-performance solar panel designed to deliver maximum efficiency with a rated power of 580W. Engineered for reliability, it features an open circuit voltage of 51.47V, making it ideal for various energy applications.
Full specifications
Electrical
| Rated Maximum Power (Pmax) | 580W |
|---|---|
| Open Circuit Voltage (Voc) | 51.47V |
| Short Circuit Current (Isc) | 14.37A |
| Maximum Power Current (Imp) | 13.62A |
| Frame | anodized aluminium alloy |
| Front Glass | heat strengthened coated glass (0.08in / 2.0mm) |
| Back Glass | heat strengthened glass (0.08in / 2.0mm) |
| Output Cables | TÜV 1×4mm², (+)300mm, (-)200mm (support customization) |
| Temperature Coefficient Of Isc (Α_Isc) | +0.045% / °C |
| Temperature Coefficient Of Voc (Β_Voc) | -0.25% / °C |
| Temperature Coefficient Of Pmax (Γ_Pmp) | -0.29% / °C |
| Protection Level | Class II |
| Weight | 68.34 lbs / 31.0 kg |
| Dimensions | 89.68×44.65×1.18in / 2278×1134×30mm |
| Certifications | CE, IEC 61215(2021)/IEC 61730(2023), PID |
Environmental
| Maximum System Voltage | DC1500V (IEC) |
|---|---|
| Operating Temperature | 113 ± 3.6°F / 45 ± 2°C |
| Maximum Series Fuse | 30A |
| Maximum Static Load, Front | 5400Pa |
| Maximum Static Load, Back | 2400Pa |
Certifications
- CE
- IEC 61215(2021)
- IEC 61730(2023)
- PID
