Felicity Solar FLA24100-EU 2.56kWh LiFePO4 Battery Pack

Felicity Solar FLA24100-EU 25.6V 2.56kWh LiFePO4 Battery

Wide and only 154 mm deep, the FLA24100-EU weighs 27 kg on its own and 30 kg packed; up to 15 of them tie in parallel onto one 25.6 V bus for 38.4 kWh.

Battery Type: LiFePO4
Depth of Discharge (DOD): ≥95%
Cycle Life: >6,000 Cycles

AED 1incl. VAT

In stock

Full Specifications Download datasheet (PDF)

Felicity Solar FLA24100-EU 25.6V 2.56kWh LiFePO4 Battery features

454 × 380 × 154 mm, only 154 mm deep

The FLA24100-EU case is wide rather than tall, so it fits a shallow bay or a low shelf; the packed carton measures 543 × 472 × 232 mm.

27 kg net, 30 kg packed

The module itself weighs 27 kg; the 30 kg figure is the packed carton rather than the battery, and it is the number to plan lifting and delivery access around.

2,500 W and 150 A for 15 seconds

Charge and discharge power peaks at 2,500 W and current at 150 A, both rated over a 15-second window for start-up surges.

Up to 15 units in parallel for 38.4 kWh

Paralleling is capped at 15 pcs, which takes a 25.6 V bank to 38.4 kWh of storage.

2.56 kWh nominal, ≥95% depth of discharge

The 2.56 kWh figure is nominal energy; how much of it is drawn is governed by the separate ≥95% depth-of-discharge rating.

LiFePO4 cells rated above 6,000 cycles

The chemistry is LiFePO4 and the cycle-life rating is more than 6,000 cycles, backed by a warranty of 5 Years.

About the Felicity Solar FLA24100-EU 25.6V 2.56kWh LiFePO4 Battery

The Felicity Solar FLA24100-EU is a 25.6 V LiFePO4 battery module rated at 2.56 kWh of nominal energy, housed in a 454 × 380 × 154 mm case that weighs 27 kg on its own. For 15 seconds it will pass 2,500 W and 150 A, and up to 15 units tie in parallel for 38.4 kWh. We are an authorised Felicity Solar distributor and supply the FLA24100-EU from our own stock. Depth of discharge is a separate rating at ≥95%, and the cells are rated for more than 6,000 cycles — the record gives that count on its own, with no test conditions attached, so none are quoted here. Because the case is 154 mm deep rather than tall, the module suits a shallow bay or a low shelf that will not take an upright cabinet, while the packed carton is a distinct figure to plan the delivery around: 30 kg, measuring 543 × 472 × 232 mm. The warranty is 5 Years.

Specifications last updated 17 August 2026

Felicity Solar FLA24100-EU 25.6V 2.56kWh LiFePO4 Battery full specifications

Electrical

Battery Type	LiFePO4
Depth of Discharge (DOD)	≥95%
Cycle Life	>6,000 Cycles
Nominal Energy	2.56kWh
Nominal Voltage	25.6V
Peak Charge/Discharge Current (15s)	150A
Max. Charge/Discharge Power(15s)	2,500W
Scalability	Max. 15 pcs in Parallel(38.4kWh)

Mechanical

Product Weight	27KG
Package Weight	30KG
Product Dimension	454X380X154MM
Package Dimension	543X472X232MM

Frequently Asked Questions

454 × 380 × 154 mm and 27 kg for the module itself. The packed carton is a separate pair of figures — 30 kg, measuring 543 × 472 × 232 mm — so plan the delivery route on 30 kg, not on 27 kg.

2,500 W of charge or discharge power and 150 A of current, each rated over a 15-second window. Those are peak figures for start-up loads, and the record publishes no separate continuous rating.

Up to 15 pcs in parallel, which is 38.4 kWh of storage on a single 25.6 V bus. Each module contributes 2.56 kWh of nominal energy.

More than 6,000 cycles is the rated cycle life, and the warranty is 5 Years. Depth of discharge is rated separately at ≥95%; the record states the cycle count with no test conditions, so none are implied here.
